Price:
NZ$ 391.53 including GST
NZ$ 340.46 excluding GST
or four payments of $97.88
with
Learn More
each
A5584S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 80 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10.50 mm |
| Diameter (D.3) | M10x1.5 mm |
| Length (L.1) | 161 mm |
| Mount Inside Length or Pad Mount C-C (C) | 66.60 mm |
| Plug Code | PL_2004 |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 9.50 mm |
| Pulley Outside Diameter (O.D.1) | 42.30 mm |
| Pulley Outside Diameter (O.D.2) | 62 mm |
| Pulley to Mount Distance (A) | 42 mm |
| Pulley Type | Solid |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MAZDA | RX7 | 01.1989-12.1992 |
Reference Information
| 13237 | LESTER |
| 13237N | WAI / TRANSPO |
| 90-27-3143 | WILSON |
| A002T17574 | MITSUBISHI |
| A002T17574 | MITSUBISHI |
| A2T17574 | MITSUBISHI |
| A2T17574 | MITSUBISHI |
| N350-18-300 | MAZDA |
| N350-18-300A | MAZDA |
| N350-18-300B | MAZDA |
| TA000N22401 | MANDO |
| UD103017A | AS-PL |
