Price:
NZ$ 343.37 including GST
NZ$ 298.58 excluding GST
or four payments of $85.84
with
Learn More
each
A6839S
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
Specifications
| Amp | 20 A |
| Bottom Mounting Foot Width (B) | 20 mm |
| Diameter (D.1) | 8.50 mm |
| Diameter (D.2) | M8x1.25 mm |
| Diameter (D.3) | 8.50 mm |
| Length (L.1) | 148 mm |
| Mount Inside Length or Pad Mount C-C (C) | 66.50 mm |
| Plug Code | PL_2500 |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 15 mm |
| Pulley Outside Diameter (O.D.1) | 43 mm |
| Pulley Outside Diameter (O.D.2) | 76 mm |
| Pulley to Mount Distance (A) | 47 mm |
| Pulley Type | Solid |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | 5FD-20 | ||
| TOYOTA | 5FD-23 | ||
| TOYOTA | 5FD-25 | ||
| TOYOTA | 5FD-28 | ||
| TOYOTA | 5FD-30 |
Reference Information
| 100211-4100 | DENSO |
| 100211-4101 | DENSO |
| 100211-4103 | DENSO |
| 100211-4104 | DENSO |
| 113201 | FARCOM |
| 12210N | WAI / TRANSPO |
| 196.506.020.050 | PSH |
| 27060-78300 | TOYOTA |
| 27060-78300-71 | TOYOTA |
| 27060-96300 | TOYOTA |
| 27070-23060 | TOYOTA |
| 27070-23060-71 | TOYOTA |
| 3114625 | HENKEL PARTS |
| 3114626 | HENKEL PARTS |
| 445809 | LOGISTIK |
| 555141RI | KUHNER |
| ALN5214 | KRAUF |
| ALT0364 | 3EFFE |
| ALT30142 | WOODAUTO |
| ALT6039 | ELECTROLOG |
| G101366 | BTS TURBO |
| UD102582A | AS-PL |
| WOOALT30142 | WOODAUTO |
