Price:
NZ$ 646.67 including GST
NZ$ 562.32 excluding GST
or four payments of $161.67
with
Learn More
each
A6840S
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
Specifications
| Amp | 100 A |
| Diameter (D.1) | 8.50 mm |
| Diameter (D.2) | 8.50 mm |
| Diameter (D.3) | 11 mm |
| Length (L.1) | 163 mm |
| Mount Inside Length or Pad Mount C-C (C) | 50 mm |
| Pad mount thickness (E.1) | 48 mm |
| Pad mount thickness (E.2) | 48 mm |
| Plug Code | PL_2306 |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 52 mm |
| Pulley to Mount Distance (A) | 33 mm |
| Pulley Type | Clutch |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Auris 1.2 | [8NR-FTS] | 03.2015-12.2018 |
| TOYOTA | Corolla 1.2 | [8NR-FTS] | 01.2019- |
| TOYOTA | Corolla 1.2 | [8NR-FTS] | 02.2019- |
Reference Information
| 104211-3920 | DENSO |
| 104211-3921 | DENSO |
| 115366 | FARCOM |
| 195.341.100.050 | PSH |
| 21815N | WAI / TRANSPO |
| 2353691002 | DRI |
| 27060-0Y230 | TOYOTA |
| 28-7993 | ELSTOCK |
| 40674 | CEVAM |
| 556170RI | KUHNER |
| 58407 | EAI |
| 89216801 | POWERMAX |
| AEG1495 | AUTOELECTRO |
| AL04257 | TMI |
| G105494 | BTS TURBO |
| LRA04384 | LUCAS |
| LRA4384 | LUCAS |
| TO8139 | SNRA |
| UD102560A | AS-PL |
