Price:
NZ$ 400.52 including GST
NZ$ 348.28 excluding GST
or four payments of $100.13
with
Learn More
each
A6841S
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
Specifications
| Amp | 70 A |
| Bottom Mounting Foot Width (B) | 28 mm |
| Diameter (D.1) | 8.50 mm |
| Diameter (D.2) | 10.50 mm |
| Diameter (D.3) | 10.50 mm |
| Length (L.1) | 164 mm |
| Mount Inside Length or Pad Mount C-C (C) | 43 mm |
| Plug Code | PL_3314 |
| Pulley Grooves | 5 qty |
| Pulley Outside Diameter (O.D.1) | 55 mm |
| Pulley to Mount Distance (A) | 52 mm |
| Pulley Type | Solid |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Carina E 1.6 | [4A-FE] | 01.1993-09.1997 |
| TOYOTA | Carina E 1.6 | [4A-FE] | 01.1995-09.1997 |
| TOYOTA | Carina E 1.6 | [4A-FE] | 04.1992-09.1997 |
| TOYOTA | Carina E 1.6 | [4A-FE] | 10.1995-09.1997 |
| TOYOTA | Carina E 1.6 | [4A-FE] | 12.1993-09.1997 |
| TOYOTA | Carina E 1.6 16V | [4A-FE] | 10.1995-09.1997 |
| TOYOTA | Carina E 1.6 16V | [4A-FE] | 12.1994-09.1997 |
| TOYOTA | Carina E 1.6 GLi | [4A-FE] | 01.1993-09.1997 |
| TOYOTA | Carina E 1.6 GLi | [4A-FE] | 04.1992-09.1997 |
| TOYOTA | Carina E 1.6 i | [4A-FE] | 02.1995-09.1997 |
| TOYOTA | Carina E 1.8 | [7A-FE] | 01.1995-09.1997 |
| TOYOTA | Carina E 1.8 i | [7A-FE] | 02.1995-09.1997 |
| TOYOTA | Carina E 1.8 i 16V | [7A-FE] | 01.1995-09.1997 |
| TOYOTA | Celica 1.8 i 16V | [7A-FE] | 11.1993-11.1999 |
| TOYOTA | Corolla 1.6 | [4A-F] | 09.1994-12.1997 |
| TOYOTA | Corolla 1.6 | [4A-FE] | 04.1997-02.2000 |
| TOYOTA | Corolla 1.6 | [4A-FE] | 05.1992-04.1997 |
| TOYOTA | Corolla 1.6 | [4A-FE] | 05.1995-02.2000 |
| TOYOTA | Corolla 1.6 | [4A-FE] | 05.1997-02.2000 |
| TOYOTA | Corolla 1.6 | [4A-FE] | 05.1997-08.2001 |
| TOYOTA | Corolla 1.6 | [4A-FE] | 09.1991-07.1995 |
| TOYOTA | Corolla 1.6 | [4A-FE] | 09.1994-12.1997 |
| TOYOTA | Corolla 1.6 GLi | [4A-FE] | 07.1992-04.1997 |
| TOYOTA | Corolla 1.6 i | [4A-FE] | 09.1994-11.1999 |
| TOYOTA | Corolla 1.6 Si | [4A-FE] | 07.1992-04.1997 |
| TOYOTA | Corolla 1.6 Si | [4A-FE] | 09.1995-04.1997 |
| TOYOTA | Corolla 1.8 | [7A-FE] | 09.1992-04.1997 |
| TOYOTA | Corolla 1.8 | [7A-FE] | 10.1997-10.2001 |
| TOYOTA | Corolla 1.8 16V 4WD | [7A-FE] | 09.1995-04.1997 |
| TOYOTA | Corolla 1.8 4WD | [7A-FE] | 04.1997-10.2001 |
| TOYOTA | Corolla 1.8 GT | [7A-FE] | 11.1992-05.1995 |
| TOYOTA | Corolla 1.8 GTi 4WD | [7A-FE] | 05.1992-07.1995 |
Reference Information
| 002-T515 | ASHIKA |
| 002-T537 | ASHIKA |
| 0986040471 | BOSCH |
| 0986042331 | BOSCH |
| 100211-8991 | DENSO |
| 101211-0060 | DENSO |
| 101211-0061 | DENSO |
| 101211-0062 | DENSO |
| 101211-0080 | DENSO |
| 101211-0120 | DENSO |
| 101211-0181 | DENSO |
| 101211-4580 | DENSO |
| 101211-5020 | DENSO |
| 101211-5080 | DENSO |
| 101211-5240 | DENSO |
| 101211-9500 | DENSO |
| 102211-1110 | DENSO |
| 10441911 | ALANKO |
| 111579 | CARGO |
| 12060400 | EUROTEC |
| 13482N | WAI / TRANSPO |
| 195.524.070.050 | PSH |
| 195.524.070.415 | PSH |
| 195.524.070.461 | PSH |
| 195.524.070.462 | PSH |
| 1986A01292 | BOSCH |
| 20040110AV | ITAB AUTOMOTIVE |
| 20110210 | PRESTOLITE |
| 20132011BN | REAL |
| 2040110.0 | SANDO |
| 210266A | ERA |
| 210266R | ERA |
| 235141702 | DRI |
| 27060-02040 | TOYOTA |
| 27060-02050 | TOYOTA |
| 27060-15080 | TOYOTA |
| 27060-15080-84 | TOYOTA |
| 27060-15090 | TOYOTA |
| 27060-15100 | TOYOTA |
| 27060-15110 | TOYOTA |
| 27060-15120 | TOYOTA |
| 27060-15130 | TOYOTA |
| 27060-15140 | TOYOTA |
| 27060-16390 | TOYOTA |
| 28-1821 | ELSTOCK |
| 2T515 | JAPKO |
| 2T537 | JAPKO |
| 3114073 | HENKEL PARTS |
| 40976RI | KUHNER |
| 437514 | VALEO |
| 56617 | EAI |
| 617ST65 | STARTCAR |
| 802-17080 | IAP QUALITY PARTS |
| 8EL012427-821 | HELLA |
| 8EL732741-001 | HELLA |
| 9279 | CEVAM |
| 944390512860 | MAGNETI MARELLI |
| A-30304 | DTS |
| ADN110A | AUTOTEAM |
| AL01014 | TMI |
| ALN0976 | KRAUF |
| ALT0551 | 3EFFE |
| ALT30304 | WOODAUTO |
| ALT3065 | 3EFFE |
| ALT5041 | WOODAUTO |
| ALT515 | JAPANPARTS |
| ALT537 | JAPANPARTS |
| ALT6087 | ELECTROLOG |
| BBA2200 | BORG & BECK |
| CAL40110AS | CASCO |
| CAR-821444 | COMLINE |
| CGB-13503 | AINDE |
| DRA3503 | DELCO |
| F032111579 | CARGO |
| G101501 | BTS TURBO |
| G105207 | BTS TURBO |
| IR6878 | PROTECH |
| J5112086 | HERTH+BUSS |
| JA976IR | HC PARTS |
| L40470 | ATL AUTOTECHNIK |
| LEA0189 | LE PART |
| LRB00210 | LUCAS |
| LRB210 | LUCAS |
| MRA51286 | MAGNETI MARELLI |
| QRA2368 | QUINTON HAZELL |
| STX100650R | STARDAX |
| TO8040 | SNRA |
| TT11851 | TESLA |
| UD102501A | AS-PL |
| WG2011732 | WILMINK GROUP |
| WG2280657 | WILMINK GROUP |
| WG2283144 | WILMINK GROUP |
| WOOALT30304 | WOODAUTO |
| WOOALT5041 | WOODAUTO |
