Associated Numbers
anj280 65-8313 dxa4220
0986CR0016
Bosch Exchange
0986UR0016
Bosch Exchange
1012110530
Denso
1012110531
Denso
1012110532
Denso
1012110540
Denso
1012110541
Denso
1012110542
Denso
1012110543
Denso
1022115240
Denso
10464177
Delco Remy
112358
HC-Cargo
113091
HC-Cargo
1193001ND
WAI
13512N
WAI
13512R
WAI
195594055
PSH
1986A00453
Bosch
1986A01418
Bosch
2706030530
Toyota
2706075011
Toyota
2706075020
Toyota
2706075030
Toyota
2706075040
Toyota
3211521
Delco Remy
90295256
Wilson
90295489
Wilson
9761211053
Denso
A8436
Dixie
AL3279X
Bosch (USA)
ALT30226
Wood Auto
ALT30245
Wood Auto
DRA0773
Delco Remy
F032112358
HC-Cargo
F042205002
Bosch
HJA1536IR
HC-Parts
JA1536IR
HC-Parts
LRA01813
Lucas
LRA1813
Lucas
RNL0530ND
RNL
RNL0530NDT
RNL
WOOALT30226
Wood Auto
WOOALT30245
Wood Auto
Specifications
| Amp | 60 A |
| Bottom Mounting Foot Width (B) | 58 mm |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | M8x1.25 mm |
| Length (L.1) | 152 mm |
| Plug Code | PL_3414 |
| Pulley Grooves | 5 qty |
| Pulley Outside Diameter (O.D.1) | 53.50 mm |
| Pulley to Mount Distance (A) | 91 mm |
| Pulley Type | Solid |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Hiace 2.4 | [2RZ] | 08.1989-07.1998 |
| TOYOTA | Hiace 2.4 | [2RZ-E] | 08.1995-04.1998 |
| TOYOTA | Hiace 2.4 | [2RZ-E] | 08.1995-11.2003 |
| TOYOTA | Hiace 2.4 4WD | [2RZ-E] | 08.1995-04.1998 |
Reference Information
| 0986CR0016 | BOSCH |
| 0986UR0016 | BOSCH |
| 101211-0530 | DENSO |
| 101211-0531 | DENSO |
| 101211-0532 | DENSO |
| 101211-0540 | DENSO |
| 101211-0541 | DENSO |
| 101211-0542 | DENSO |
| 101211-0543 | DENSO |
| 102211-5240 | DENSO |
| 112358 | CARGO |
| 112793 | FARCOM |
| 113091 | CARGO |
| 13512N | WAI / TRANSPO |
| 195.594.055.050 | PSH |
| 27060-30530 | TOYOTA |
| 27060-75040 | TOYOTA |
| 27060-75040-84 | TOYOTA |
| 3114354 | HENKEL PARTS |
| 3114355 | HENKEL PARTS |
| 442804 | ALANKO |
| 9213999 | POWERMAX |
| A131.524 | PSH |
| AL3279X | BOSCH |
| ALN3093 | KRAUF |
| ALT30245 | WOODAUTO |
| CAR-821904 | COMLINE |
| DRA0773 | DELCO |
| F032112358 | CARGO |
| F032113091 | CARGO |
| G101454 | BTS TURBO |
| G105219 | BTS TURBO |
| HJA1536IR | HC PARTS |
| IR6991 | PROTECH |
| JA1536IR | HC PARTS |
| RNL0530ND | RNL |
| RNL0530NDT | RNL |
| UD90110A | AS-PL |
| WOOALT30226 | WOODAUTO |
| WOOALT30245 | WOODAUTO |
