Price:
NZ$ 379.64 including GST
NZ$ 330.12 excluding GST
or four payments of $94.91
with
Learn More
each
A9105S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 70 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | M10x1.25 mm |
| Diameter (D.3) | 10.50 mm |
| Length (L.1) | 156 mm |
| Mount Inside Length or Pad Mount C-C (C) | 65 mm |
| Plug Code | PL_2004 |
| Pulley Grooves | 4 qty |
| Pulley Outside Diameter (O.D.1) | 58 mm |
| Pulley to Mount Distance (A) | 39 mm |
| Pulley Type | Solid |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| KIA | Retona 2.0 16V | [FE] | 05.2000-12.2001 |
| KIA | Sportage 2.0 | [FE] | 10.2000-08.2003 |
| KIA | Sportage 2.0 4WD | [FE] | 10.2000-08.2003 |
| KIA | Sportage 2.0 i 16V | [FE] | 10.1999-08.2003 |
| KIA | Sportage 2.0 i 16V 4WD | [FE] | 04.1994-08.2003 |
| KIA | Sportage 2.0 i 4WD | [FE] | 04.1994-08.1999 |
Reference Information
| 002-M943 | ASHIKA |
| 0K011-18-300 | HYUNDAI / KIA |
| 0K011-18-300B | HYUNDAI / KIA |
| 0K011-18-300C | HYUNDAI / KIA |
| 0K011-18-300D | HYUNDAI / KIA |
| 0K011-83-00B | HYUNDAI / KIA |
| 0K012-18-300 | HYUNDAI / KIA |
| 111787 | CARGO |
| 12060849 | EUROTEC |
| 13646N | WAI / TRANSPO |
| 20041104AV | ITAB AUTOMOTIVE |
| 20041104OV | ITAB AUTOMOTIVE |
| 20128401BN | REAL |
| 20128401OE | REAL |
| 2041104.0 | SANDO |
| 2041104.1 | SANDO |
| 210373 | ERA |
| 224141702 | DRI |
| 255.503.070.000 | PSH |
| 255.503.070.360 | PSH |
| 255.503.070.550 | PSH |
| 28-2977 | ELSTOCK |
| 2M943 | JAPKO |
| 3116380 | HENKEL PARTS |
| 401537RI | KUHNER |
| 401537RIV | KUHNER |
| 446586 | LOGISTIK |
| 56708 | EAI |
| 708ST65 | STARTCAR |
| 89213851 | POWERMAX |
| 8EL737851-001 | HELLA |
| 90-31-7010 | WILSON |
| 90-31-7010N | WILSON |
| 9051330 | FRIESEN |
| 9173 | CEVAM |
| 9213851 | POWERMAX |
| 944390513300 | MAGNETI MARELLI |
| A12VA0817A2 | SIDAT |
| AB170035 | MANDO |
| AC-JBA1537 | ACAUTO |
| AG0393 | GHIBAUDI |
| AG0393RB | GHIBAUDI |
| AL01633 | TMI |
| ALA1537 | KRAUF |
| ALM943 | JAPANPARTS |
| ALT0006 | 3EFFE |
| ALT35008 | WOODAUTO |
| ALT8711 | ELECTROLOG |
| ALTW966 | 3EFFE |
| ANM35668 | ANDEL |
| APO104 | AUTOTEAM |
| BBA2444 | BORG & BECK |
| CAL41104AS | CASCO |
| CAL41104GS | CASCO |
| DRA3448 | DELCO |
| F032111787 | CARGO |
| G103468 | BTS TURBO |
| IR6867 | PROTECH |
| J5113030 | NIPPARTS |
| JA1537IR | HC PARTS |
| K511A01 | NPS |
| K80528OEM | STARDAX |
| KI8001 | SNRA |
| L81260 | ATL AUTOTECHNIK |
| LEA0353 | LE PART |
| LRA01714 | LUCAS |
| LRA1714 | LUCAS |
| MRA51330 | MAGNETI MARELLI |
| OK011-18-300 | HYUNDAI / KIA |
| OK011-18-300B | HYUNDAI / KIA |
| OK011-18-300C | HYUNDAI / KIA |
| OK011-18-300D | HYUNDAI / KIA |
| OK011-83-00B | HYUNDAI / KIA |
| OK012-18-300 | HYUNDAI / KIA |
| QRA1885 | QUINTON HAZELL |
| STX100663R | STARDAX |
| TA000A08101Z | VALEO |
| TT11732 | TESLA TECHNICS |
| UD102798A | AS-PL |
| WG2011837 | WILMINK GROUP |
| WOOALT35008 | WOODAUTO |
