Price:
NZ$ 287.30 including GST
NZ$ 249.83 excluding GST
or four payments of $71.83
with
Learn More
each
A9525S
No stock in NZ currently
No stock in NZ currently
Specifications
| Amp | 55 A |
| Bottom Mounting Foot Width (B) | 32 mm |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 11 mm |
| Length (L.1) | 170 mm |
| Plug Code | PL_9105 |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 10 mm |
| Pulley Outside Diameter (O.D.1) | 43.50 mm |
| Pulley Outside Diameter (O.D.2) | 68 mm |
| Pulley to Mount Distance (A) | 52 mm |
| Pulley Type | Solid |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUTOBIANCHI | Y10 1.0 | [156A2.000] | 03.1985- |
| AUTOBIANCHI | Y10 1.0 | [156A2.246] | 01.1989-09.1992 |
| AUTOBIANCHI | Y10 1.0 4WD | [156A3.000] | 09.1986-12.1988 |
| AUTOBIANCHI | Y10 1.0 Turbo | [156A1.000] | 03.1985-12.1988 |
| AUTOBIANCHI | Y10 1.1 | [156C.000] | 06.1989-09.1992 |
| AUTOBIANCHI | Y10 1.1 4WD | [156C.000] | 06.1989-09.1992 |
| AUTOBIANCHI | Y10 1.1 i.e. | [156C.046] | 09.1990-01.1995 |
| FIAT | Panda 0.8 | [156A4.000] | 01.1986-12.1992 |
| FIAT | Panda 0.8 | [156A4.000] | 01.1995-12.1997 |
| FIAT | Panda 0.8 | [156A4.048] | 01.1995-12.1997 |
| FIAT | Panda 1.0 | [156A2.048] | 01.1986-07.1989 |
| FIAT | Panda 1.0 | [156A2.048] | 07.1989-04.1992 |
| FIAT | Panda 1.0 | [156A2.100] | 03.1989-06.1990 |
| FIAT | Panda 1.0 | [156A.3000] | 07.1990-12.1992 |
| FIAT | Panda 1.0 | [156A3.100] | 01.1986-02.1992 |
| FIAT | Panda 1.0 4x4 | [156A2.100] | 03.1989-06.1990 |
| FIAT | Panda 1.0 4x4 | [156A3.000] | 01.1986-06.1990 |
| FIAT | Panda 1.0 4x4 | [156A3.000] | 07.1990-12.1992 |
| FIAT | Panda 1.0 4x4 | [156A3.100] | 03.1989-06.1990 |
| FIAT | Panda 1.0 i.e. | [141C2.000] | 01.1995-09.2003 |
| FIAT | Panda 1.0 i.e. | [156A2.246] | 07.1990-02.2004 |
| FIAT | Panda 1.0 i.e. 4x4 | [156A2.246] | 05.1986-06.1990 |
| FIAT | Panda 1.0 i.e. 4x4 | [156A2.246] | 07.1990-04.1992 |
| FIAT | Panda 1.0 i.e. 4x4 | [176B2.000] | 02.1995-09.2003 |
| FIAT | Panda 1.1 4x4 trekking | [156C.046] | 10.1991-07.2004 |
| FIAT | Panda 1.1 Selecta | [156C.046] | 03.1992-03.1997 |
| FIAT | Panda 1.1 Selecta | [176B2.000] | 02.1995-09.2003 |
| FIAT | Panda 1.1 Selecta | [187A1.000] | 02.1995-09.2003 |
| FIAT | Tipo 1.1 Digit | [160A3.000] | 07.1987-03.1993 |
| FIAT | Uno 1.0 | [156A2.048] | 06.1986-05.1991 |
| FIAT | Uno 1.0 | [156A2.100] | 06.1986-03.1994 |
| FIAT | Uno 1.0 | [156A2.100] | 06.1986-10.2002 |
| FIAT | Uno 1.0 i.e. | [156A2.246] | 08.1985-09.1992 |
| FIAT | Uno 1.1 | [146A4.044] | 01.1986-12.1989 |
| FIAT | Uno 1.1 | [156C.046] | 01.1990-12.1993 |
| FIAT | Uno 1.1 | [160A3.000] | 04.1989-12.1992 |
| FIAT | Uno 1.1 i.e. | [146C3.000] | 09.1989-03.1994 |
| LANCIA | Y10 1.0 Fire | [156A2.000] | 03.1985-06.1989 |
| LANCIA | Y10 1.0 Fire | [156A2.100] | 03.1989-06.1991 |
| LANCIA | Y10 1.0 Fire | [156A2.246] | 10.1987-02.1992 |
| LANCIA | Y10 1.0 Fire 4WD | [156A2.000] | 09.1986-02.1989 |
| LANCIA | Y10 1.0 Fire 4WD | [156A2.100] | 03.1989-06.1991 |
| LANCIA | Y10 1.0 Fire 4WD | [156A2.246] | 12.1987-02.1992 |
| LANCIA | Y10 1.1 Avenue | [176B2.000] | 09.1992-12.1995 |
| LANCIA | Y10 1.1 Avenue 4WD | [176B2.000] | 09.1992-12.1995 |
| LANCIA | Y10 1.1 i.e. | [156C.000] | 01.1989-09.1992 |
| LANCIA | Y10 1.1 i.e. 4WD | [156C.000] | 01.1989-09.1992 |
Reference Information
| 0000007565832 | FIAT |
| 0000046231660 | FIAT |
| 011-003-000278R | REMANTE |
| 063320034 | MAGNETI MARELLI |
| 063321067 | MAGNETI MARELLI |
| 063321067010 | MAGNETI MARELLI |
| 063321198 | MAGNETI MARELLI |
| 0986035641 | BOSCH |
| 10441942 | ALANKO |
| 111621 | CARGO |
| 11.201.358 | ISKRA / LETRIKA |
| 20030139AV | ITAB AUTOMOTIVE |
| 20104931BN | REAL |
| 20104931OE | REAL |
| 20104931RC | REAL |
| 2030139.0 | SANDO |
| 2030139.1 | SANDO |
| 2030139.2 | SANDO |
| 20696N | WAI / TRANSPO |
| 210213 | ERA |
| 218112552 | DRI |
| 2541399 | VALEO |
| 28-0733 | ELSTOCK |
| 30572RI | KUHNER |
| 30572RIM | KUHNER |
| 3119052 | HENKEL PARTS |
| 3119054 | HENKEL PARTS |
| 433085 | VALEO |
| 436118 | VALEO |
| 440497 | LOGISTIK |
| 443192 | VALEO |
| 46231660 | FIAT |
| 505.017.055.090 | PSH |
| 505.017.055.311 | PSH |
| 505.017.055.461 | PSH |
| 505.017.055.462 | PSH |
| 5530107 | MEAT & DORIA |
| 55604 | EAI |
| 604ST55 | STARTCAR |
| 63320034010 | MAGNETI MARELLI |
| 63321198010 | MAGNETI MARELLI |
| 72735204 | MAHLE |
| 7L65832AA | VW |
| 8550505029 | MOTRIO |
| 8EL012427-371 | HELLA |
| 8EL725861-001 | HELLA |
| 9035645 | FRIESEN |
| 9120690411 | BOSCH |
| A12ML0265A2 | SIDAT |
| A132.729 | PSH |
| A146.140 | PSH |
| AAK4177 | ISKRA / LETRIKA |
| AC-CBA0572 | ACAUTO |
| AG0167 | GHIBAUDI |
| AG0167RB | GHIBAUDI |
| AI-90282 | AINDE |
| AL00498 | TMI |
| ALE0350 | KRAUF |
| ALT20723 | WOODAUTO |
| ALT321390 | SIOM |
| ALT321390A | SIOM |
| ALT7857 | ELECTROLOG |
| AMM139A | AUTOTEAM |
| ANM35629 | ANDEL |
| BREF0320986035641 | CARWOOD GROUP |
| CA572IR | HC PARTS |
| CAL30139AS | CASCO |
| CAL30139GS | CASCO |
| CAL30139RS | CASCO |
| CAR-821160 | COMLINE |
| DAN574 | DENSO |
| DAN612 | DENSO |
| DRA3409 | DELCO |
| DRA3409N | DELCO |
| DRA5641 | DELCO |
| DRA5641N | DELCO |
| DRA5641X | DELCO |
| F032111621 | CARGO |
| FI8019 | SNRA |
| G101912 | BTS TURBO |
| G104821 | BTS TURBO |
| G106416 | BTS TURBO |
| H5530107 | HOFFER |
| HCA572IR | HC PARTS |
| IA0358 | ISKRA / LETRIKA |
| IR7610 | PROTECH |
| L35645 | ATL AUTOTECHNIK |
| LEA0672 | LUCAS |
| LEA0672 | LE PART |
| LEA672 | LUCAS |
| LETIA0358 | WOODAUTO |
| MAHMG205 | WOODAUTO |
| MAN300 | MAGNETI MARELLI |
| MG205 | MAHLE |
| NA335 | VALEO |
| QRA1544 | QUINTON HAZELL |
| STX100346R | STARDAX |
| STX100502 | STARDAX |
| UD03905A | AS-PL |
| WG2011674 | WILMINK GROUP |
| WG2043478 | WILMINK GROUP |
| WG2196956 | WILMINK GROUP |
| WG2280575 | WILMINK GROUP |
| WOOALT20723 | WOODAUTO |
