Price:
NZ$ 609.62 including GST
NZ$ 530.10 excluding GST
or four payments of $152.41
with
Learn More
each
A9527S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 175 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 1/2" UNF 13 mm |
| Diameter (D.2) | 13 mm |
| Diameter (D.3) | 13 mm |
| Length (L.1) | 207 mm |
| Mount Inside Length or Pad Mount C-C (C) | 103.50 mm |
| Plug Code | PL_9105 |
| Pulley Type | No Pulley |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | Magnum 220 | [MU7-220H.P.] | 09.2006- |
| CASE | Magnum 225 8.3 | [MU7-225H.P.] | 09.2006- |
| CASE | Magnum 240 | [MU7-240H.P.] | 09.2006- |
| CASE | Magnum 250 8.3 | [Tier3-252H.P.] | |
| CASE | Magnum 255 | [MU7-255H.P.] | 08.2006- |
| CASE | Magnum 270 | [MU7-270H.P.] | 09.2006- |
| CASE | Magnum 280 8.3 | [MU7-280H.P.] | 09.2006- |
| CASE | Magnum 305 | [MU7-305-H.P.] | 09.2006- |
| CASE | Magnum 335 8.9 | [MU7-335H.P.] | 09.2006- |
| NEW HOLLAND | Patriot 250 4.5 | [FPT-NEF] | |
| NEW HOLLAND | SP2500 4.5 | [FPT-NEF] | |
| NEW HOLLAND | T8010 | [CDC] | 01.2006- |
| NEW HOLLAND | T8020 | ||
| NEW HOLLAND | T8030 | [CDC] | 01.2006- |
| NEW HOLLAND | T8040 | [CDC] | |
| NEW HOLLAND | T8050 9.0 | [CDC-358H.P.] | |
| NEW HOLLAND | TG215 8.3 | 01.2008- | |
| NEW HOLLAND | TG245 8.3 | 01.2008- | |
| NEW HOLLAND | TG275 8.3 | 01.2008- | |
| NEW HOLLAND | TG305 8.3 | 01.2008- |
Reference Information
| 11.203.191 | ISKRA / LETRIKA |
| 11.203.720 | ISKRA / LETRIKA |
| 11.204.238 | ISKRA / LETRIKA |
| 11.204.401 | ISKRA / LETRIKA |
| 113327 | FARCOM |
| 114469 | CARGO |
| 20021626OV | ITAB AUTOMOTIVE |
| 20119382BN | REAL |
| 20119382OE | REAL |
| 20119626OE | REAL |
| 2021283.0 | SANDO |
| 2021283.1 | SANDO |
| 2021626.1 | SANDO |
| 20925N | WAI / TRANSPO |
| 2469 | CEVAM |
| 282-30243 | ROBERT'S |
| 28-6645 | ELSTOCK |
| 3123816 | HENKEL PARTS |
| 554747RI | KUHNER |
| 554747RIB | KUHNER |
| 554747RIP | KUHNER |
| 554747RIS | KUHNER |
| 5851101752 | DRI |
| 635.519.175.090 | PSH |
| 635.519.175.310 | PSH |
| 72735268 | MAHLE |
| 72740633 | MAHLE |
| 87418226 | CASE |
| 87645567 | CASE |
| 89215989 | POWERMAX |
| 90-23-6588 | WILSON |
| A134.092 | PSH |
| AAK5834 | ISKRA / LETRIKA |
| AAN5150 | ISKRA / LETRIKA |
| AAN5702 | ISKRA / LETRIKA |
| AAN5834 | ISKRA / LETRIKA |
| AAN8150 | ISKRA / LETRIKA |
| AL03142 | TMI |
| ALT20655 | WOODAUTO |
| ALT20690 | WOODAUTO |
| ALT20754 | WOODAUTO |
| ALT232830A | SIOM |
| ALT236260 | SIOM |
| ALT7853 | ELECTROLOG |
| ALTE732 | 3EFFE |
| CAL21283AS | CASCO |
| CAL21283GS | CASCO |
| CAL21626GS | CASCO |
| F032114469 | CARGO |
| G104876 | BTS TURBO |
| IA1332 | ISKRA / LETRIKA |
| LETIA1332 | WOODAUTO |
| LRA03535 | LUCAS |
| LRA3535 | LUCAS |
| MAHMG269 | WOODAUTO |
| MG269 | MAHLE |
| MG697 | MAHLE |
| PRAE732 | 3EFFE |
| UD102788A | AS-PL |
| WOOALT20655 | WOODAUTO |
| WOOALT20690 | WOODAUTO |
| WOOALT20754 | WOODAUTO |
