Price:
NZ$ 470.37 including GST
NZ$ 409.02 excluding GST
or four payments of $117.59
with
Learn More
each
S01037S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 3.20 kW |
| Length (L.1) | 293 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | 12.50 mm |
| Mount Hole Diameter (C.2) | 12.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 22 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DEUTZ | Engine | [F1L410] | 01.1968-12.1974 |
| DEUTZ | Engine | [F2L411D] | 01.1975-12.1985 |
| DEUTZ | Engine 1.3 | [F2L410] | 01.1967-12.1977 |
| DEUTZ | Engine 1.4 | [F2L411] | 01.1973-12.1975 |
| KHD | Engine | [F1L410] | 01.1968-12.1978 |
| KHD | Engine 1.3 | [F2L410] | 01.1967-12.1973 |
| KHD | Engine 1.4 | [F2L411] |
Reference Information
| 0001363112 | BOSCH |
| 01172904 | KHD |
| 10010749AV | ITAB AUTOMOTIVE |
| 1172904 | KHD |
| 20401947BN | REAL |
| 255072 | KUHNER |
| 3120257 | HENKEL PARTS |
| 551.027.092.010 | PSH |
| 551.027.092.016 | PSH |
| 6010749.0 | SANDO |
| 75830000854 | MAN |
| A71240 | ATL AUTOTECHNIK |
| CGB-23260 | AINDE |
| CMA-611689 | COMLINE |
| CST10749AS | CASCO |
| MAV12749 | SIOM |
| MAV127490A | SIOM |
| S100816 | BTS TURBO |
| S133.449 | PSH |
| SBO749A | AUTOTEAM |
| STB2576 | KRAUF |
| STR1815 | ELECTROLOG |
| STR50697 | WOODAUTO |
| STRF553 | 3EFFE |
| UD102910S | AS-PL |
| WOOSTR50697 | WOODAUTO |
