Price:
NZ$ 486.54 including GST
NZ$ 423.08 excluding GST
or four payments of $121.64
with
Learn More
each
S01045S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Insulated Earth | Yes |
| Kilowatt | 3.20 kW |
| Length (L.1) | 303 mm |
| Mount Hole Center - Center (O.1) | 107 mm |
| Mount Hole Diameter (C.1) | 14 mm |
| Mount Hole Diameter (C.2) | 14 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 23 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82.50 mm |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| VM | Engine | [D702] | |
| VM | Engine 2.1 | [D703] |
Reference Information
| 0001355011 | BOSCH |
| 0001355016 | BOSCH |
| 0001363115 | BOSCH |
| 0001363124 | BOSCH |
| 0058402670 | LOMBARDINI |
| 11.130.645 | ISKRA / LETRIKA |
| 11.131.479 | ISKRA / LETRIKA |
| 115537 | CARGO |
| 12153837 | KHD |
| 20419006OE | REAL |
| 254506 | KUHNER |
| 254506B | KUHNER |
| 254506M | KUHNER |
| 331778 | LOGISTIK |
| 331995 | LOGISTIK |
| 35532040F | VM |
| 35532056F | VM |
| 421.001.092.010 | PSH |
| 421.001.092.311 | PSH |
| 58402670 | LOMBARDINI |
| 6021600.1 | SANDO |
| 605720100087 | MWM |
| 72735808 | MAHLE |
| 8083 | CEVAM |
| AZJ3211 | ISKRA / LETRIKA |
| AZJ3433 | ISKRA / LETRIKA |
| B001813227 | BOSCH |
| CGB-23224 | AINDE |
| CMA-611706 | COMLINE |
| CST21600GS | CASCO |
| ED0058402670S | LOMBARDINI |
| F032115537 | CARGO |
| IS0645 | ISKRA / LETRIKA |
| MAHMS180 | WOODAUTO |
| MAV236000 | SIOM |
| MS180 | MAHLE |
| PRSS607 | 3EFFE |
| S104115 | BTS TURBO |
| STR60640 | WOODAUTO |
| STR7864 | 3EFFE |
| STRJ498 | 3EFFE |
| STRS607 | 3EFFE |
| UD102913S | AS-PL |
| WOOSTR60640 | WOODAUTO |
