Price:
NZ$ 293.73 including GST
NZ$ 255.42 excluding GST
or four payments of $73.43
with
Learn More
each
S01049S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 1.80 kW |
| Length (L.1) | 255 mm |
| Mount Hole Center - Center (O.1) | 106 mm |
| Mount Hole Diameter (C.1) | 12.50 mm |
| Mount Hole Diameter (C.2) | 12.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 18 mm |
| Rotation | ACW |
| Spigot Diameter (A) | 82 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CITROEN | GS 1.0 | [ADMD2] | 01.1973-12.1975 |
| NSU | RO-80 1.0 | [KKM] | 01.1967-12.1977 |
| VOLVO PENTA | Engine | [MD5] | 01.1975-12.1981 |
| VOLVO PENTA | Engine 0.7 D | [MD6A] | 01.1971-12.1979 |
| VOLVO PENTA | Engine 0.7 D | [MD7A] | 01.1971-12.1979 |
| VOLVO PENTA | Engine 0.7 D | [MD7B] | 01.1981-12.1983 |
| VOLVO PENTA | Engine 1.2 D | [MD11] | 01.1975-12.1983 |
| VOLVO PENTA | Engine 1.6 D | [MD17] | 01.1975-12.1984 |
Reference Information
| 0001312001 | BOSCH |
| 0001314039 | BOSCH |
| 0001315002 | BOSCH |
| 01529053002S | VOLVO |
| 103996 | FARCOM |
| 10957 | KUHNER |
| 111210 | CARGO |
| 113705 | CARGO |
| 120-30205 | ROBERT'S |
| 25-0203 | ELSTOCK |
| 25-0203CT | AINDE |
| 260-21105 | DIXIE |
| 331759 | LOGISTIK |
| 3803073 | VOLVO |
| 5121701501000 | VW |
| 5417601 | PEUGEOT |
| 638006112 | DRI |
| 810.015.112.010 | PSH |
| 810.015.112.011 | PSH |
| 833031 | VOLVO |
| 833081 | VOLVO |
| 833669 | VOLVO |
| 838060 | VOLVO |
| 8EA737-103-001 | HELLA |
| AC-CBS0957 | ACAUTO |
| AC-CBS5497 | ACAUTO |
| ANM99366 | ANDEL |
| BOS0001315002 | WOODAUTO |
| BREF032113705 | CARWOOD GROUP |
| CS957 | HC PARTS |
| F032111210 | CARGO |
| F032113705 | CARGO |
| LRS01032 | LUCAS |
| LRS1032 | LUCAS |
| PRSS733 | 3EFFE |
| S102517 | BTS TURBO |
| ST00109 | TMI |
| STB8722 | KRAUF |
| STR10392 | ELECTROLOG |
| STR50692 | WOODAUTO |
| STRS733 | 3EFFE |
| UD103726S | AS-PL |
| WOOSTR50692 | WOODAUTO |
