Price:
NZ$ 244.16 including GST
NZ$ 212.31 excluding GST
or four payments of $61.04
with
Learn More
each
S0375SR
No stock in NZ currently
No stock in NZ currently
Specifications
| Kilowatt | 1.10 kW |
| Length (L.1) | 201 mm |
| Mount Hole Center - Center (O.1) | 18 mm |
| Mount Hole Center - Center (O.2) | 112 mm |
| Mount Hole Center - Center (O.3) | 128 mm |
| Mount Hole Diameter (C.1) | 12.50 mm |
| Mount Hole Diameter (C.2) | 12.50 mm |
| Mount Hole Diameter (C.3) | 12.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 58 mm |
| Rotation | ACW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A3 1.2 TSi | [CBZB] | 03.2010-05.2013 |
| AUDI | A3 1.2 TSi | [CBZB] | 04.2010-08.2012 |
| AUDI | A3 1.2 TSi Sportback | [CBZB] | 04.2010-03.2013 |
| SEAT | Altea 1.2 TSi | [CBZB] | 04.2010- |
| SEAT | Altea XL 1.2 TSi | [CBZB] | 04.2010- |
| SEAT | Leon 1.2 TSi | [CBZB] | 02.2010- |
| SKODA | Octavia 1.2 TSi | [CBZB] | 02.2010- |
| SKODA | Yeti 1.2 TSi | [CBZB] | 09.2009- |
| VW | Caddy 1.2 CDTi 16V | [CBZA] | 09.2010- |
| VW | Caddy 1.4 | [BCA] | 03.2004-05.2006 |
| VW | Caddy 1.4 16V | [BUD] | 05.2006-08.2010 |
| VW | Caddy 1.6 | [BGU] | 04.2004-05.2005 |
| VW | Caddy 1.6 | [BSE] | 06.2005- |
| VW | Caddy 1.6 | [BSF] | 03.2005- |
| VW | Caddy 1.6 | [BSF] | 06.2005- |
| VW | Caddy 1.6 BiFuel | [CHGA] | 05.2011- |
| VW | Caddy 2.0 EcoFuel | [BSX] | 04.2006- |
| VW | Eos 1.6 FSi | [BLF] | 06.2006- |
| VW | Golf Plus 1.2 TSi | [CBZA] | 05.2010- |
| VW | Golf Plus 1.2 TSi | [CBZB] | 08.2009- |
| VW | Golf VI 1.2 TSi | [CBZA] | 05.2010-11.2012 |
| VW | Golf VI 1.2 TSi | [CBZB] | 05.2009-11.2012 |
| VW | Golf VI 1.2 TSi | [CBZB] | 06.2011- |
| VW | Golf VI 1.2 TSi | [CBZB] | 08.2009-07.2013 |
| VW | Jetta 1.2 TSi | [CBZB] | 02.2011- |
| VW | New Beetle 1.2 TSi | [CBZB] | 07.2011- |
| VW | New Beetle 1.2 TSi | [CBZB] | 12.2012- |
| VW | Passat 1.6 | [BSE] | 05.2005- |
| VW | Passat 1.6 | [BSE] | 08.2005- |
| VW | Passat 1.6 | [BSF] | 05.2005- |
| VW | Passat 1.6 FSi | [BLF] | 03.2005- |
| VW | Passat 1.6 FSi | [BLF] | 08.2005- |
| VW | Touran 1.2 TSi | [CBZB] | 05.2010- |
| VW | Touran 1.6 | [BGU] | 07.2003- |
| VW | Touran 1.6 | [BSE] | 07.2003- |
| VW | Touran 1.6 | [BSF] | 07.2003- |
| VW | Touran 1.6 FSi | [BAG] | 02.2003- |
| VW | Touran 1.6 FSi | [BLF] | 02.2003- |
| VW | Touran 1.6 FSi | [BLP] | 02.2003- |
| VW | Touran 2.0 EcoFuel | [BSX] | 02.2006- |
Reference Information
| 0001120410 | BOSCH |
| 0001120411 | BOSCH |
| 0001121410 | BOSCH |
| 0001121411 | BOSCH |
| 011-001-000056R | REMANTE |
| 063521204100 | MAGNETI MARELLI |
| 063721322010 | MAGNETI MARELLI |
| 063ST21 | STARTCAR |
| 0986020330 | BOSCH |
| 0AH911023 | VW |
| 0AH911023A | VW |
| 0AH911023AX | VW |
| 0AH911023D | VW |
| 0AH911023DX | VW |
| 0AH911023K | VW |
| 0AH911023KX | VW |
| 10010254AV | ITAB AUTOMOTIVE |
| 10010254OV | ITAB AUTOMOTIVE |
| 10015261AV | ITAB AUTOMOTIVE |
| 10015261OV | ITAB AUTOMOTIVE |
| 101322 | KUHNER |
| 101322B | KUHNER |
| 101322V | KUHNER |
| 101628 | FEBI BILSTEIN |
| 10439748 | ALANKO |
| 105283 | FARCOM |
| 11020330 | EUROTEC |
| 114175 | CARGO |
| 12063 | EAI |
| 12130334 | AES |
| 14130197 | AES |
| 1638124080 | EUROREPAR |
| 1986S00782 | BOSCH |
| 201137 | VALEO |
| 202171 | VALEO |
| 20401452BN | REAL |
| 20401452OE | REAL |
| 20401452RC | REAL |
| 20479162BN | REAL |
| 20479162OE | REAL |
| 220467 | ERA |
| 220467A | ERA |
| 25-3217 | ELSTOCK |
| 260540-6070 | DENSO |
| 2S0233R | RIDEX |
| 300.562.103.000 | PSH |
| 300.562.103.010 | PSH |
| 300.562.103.340 | PSH |
| 300.562.103.460 | PSH |
| 300.562.103.461 | PSH |
| 300.562.103.500 | PSH |
| 311201102 | DRI |
| 3116874 | HENKEL PARTS |
| 3116875 | HENKEL PARTS |
| 3116876 | HENKEL PARTS |
| 3116877 | HENKEL PARTS |
| 32687N | WAI / TRANSPO |
| 32687R | WAI / TRANSPO |
| 331447 | LOGISTIK |
| 42020330 | HERTH+BUSS |
| 438229 | VALEO |
| 442013 | VALEO |
| 458393 | VALEO |
| 460465 | VALEO |
| 4747014 | NK |
| 5015287 | MEAT & DORIA |
| 6010254.0 | SANDO |
| 6010254.1 | SANDO |
| 6010254.2 | SANDO |
| 6015261.0 | SANDO |
| 6015261.1 | SANDO |
| 8020330 | FRIESEN |
| 8550504861 | MOTRIO |
| 88212873 | POWERMAX |
| 8EA012528-101 | HELLA |
| 943213221010 | MAGNETI MARELLI |
| 944280203300 | MAGNETI MARELLI |
| A20330 | ATL AUTOTECHNIK |
| AC-CBS1322 | ACAUTO |
| ANM22550 | ANDEL |
| ANM22550X | ANDEL |
| BOS0001120410 | WOODAUTO |
| BST2469 | BORG & BECK |
| CMA-621925 | COMLINE |
| CS1322 | HC PARTS |
| CST10254AS | CASCO |
| CST10254GS | CASCO |
| CST10254RS | CASCO |
| CST15261AS | CASCO |
| CST15261GS | CASCO |
| DRT0330 | DELCO |
| DSN3026 | DENSO |
| F032114175 | CARGO |
| F042S0H096 | BOSCH |
| F042S0H098 | BOSCH |
| H5015287 | HOFFER |
| HCS1322 | HC PARTS |
| IR9665 | PROTECH |
| LRS01671 | LUCAS |
| LRS1671 | LUCAS |
| MQS1322 | MAGNETI MARELLI |
| MSN2096 | MAGNETI MARELLI |
| OAH911023 | VW |
| PRSL125 | 3EFFE |
| QRS1997 | QUINTON HAZELL |
| RE83649N | THE NEWLINE |
| RNL2033 | RNL |
| S12BH0072A2 | SIDAT |
| S12VA0072 | SIDAT |
| S12VA0072A2 | SIDAT |
| S132.366 | PSH |
| S145.463 | PSH |
| SBO254A | AUTOTEAM |
| SG0694 | GHIBAUDI |
| SG0694RB | GHIBAUDI |
| SKSTR-0330232 | STARK |
| ST01281 | TMI |
| STB1322 | KRAUF |
| STM751 | ROLLCO |
| STR1545 | ELECTROLOG |
| STR50549 | WOODAUTO |
| STRH096 | UNIPOINT |
| STRH098 | UNIPOINT |
| STRL185 | 3EFFE |
| STX200307R | STARDAX |
| SVA261 | AUTOTEAM |
| SVA261A | AUTOTEAM |
| TS12E1 | VALEO |
| TS12E1M | VALEO |
| TS12E1S | VALEO |
| TT16679 | TESLA TECHNICS |
| V10-12-21410 | VEMO |
| VAL438229 | WOODAUTO |
| VALTS12E1M | WOODAUTO |
| VW9078 | SNRA |
| WG2192581 | WILMINK GROUP |
| WG2226366 | WILMINK GROUP |
| WOOSTR50549 | WOODAUTO |
