Price:
NZ$ 281.78 including GST
NZ$ 245.03 excluding GST
or four payments of $70.45
with
Learn More
UOM:
each
Product Code:
S0894S
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 1 kW |
| Length (L.1) | 179 mm |
| Mount Hole Center - Center (O.1) | 66 mm |
| Mount Hole Center - Center (O.2) | 108 mm |
| Mount Hole Center - Center (O.3) | 71 mm |
| Mount Hole Diameter (C.1) | M8x1.25 mm |
| Mount Hole Diameter (C.2) | 9 mm |
| Mount Hole Diameter (C.3) | M8x1.25 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 11 mm |
| Rotation | CW |
| Spigot Diameter (A) | 64 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FIAT | Albea 1.3 | [188A5.000] | 09.2001-12.2009 |
| FIAT | Palio 1.0 | [178A1.000] | 04.1996-10.2003 |
| FIAT | Palio 1.0 | [178A3.011] | 04.1996-10.2003 |
| FIAT | Palio 1.2 | [178E2.000] | 06.1999-10.2002 |
| FIAT | Palio 1.3 | [178D6.011] | 03.2000-02.2003 |
| FIAT | Palio 1.3 | [188A5.000] | 03.2000-02.2003 |
| FIAT | Palio 1.3 | [188A5.000] | 09.2001-10.2004 |
| FIAT | PALIO (178_, 171_, 371_) 1.0 | 178A1.000 | 04.1996-10.2003 |
| FIAT | PALIO (178_, 171_, 371_) 1.0 | 178A3.011 | 04.1996-10.2003 |
| FIAT | PALIO Weekend (178_, 173_, 373_, 374_, 171_) 1.2 (178BXZ1A) | 178E2.000 | 06.1999-10.2002 |
| FIAT | PALIO Weekend (178_, 173_, 373_, 374_, 171_) 1.3 (1788891, 1789491, 1730250) | 178D6.011 | 03.2000-02.2003 |
| FIAT | PALIO Weekend (178_, 173_, 373_, 374_, 171_) 1.3 (1788891, 1789491, 1730250) | 188A5.000 | 03.2000-02.2003 |
| FIAT | PALIO Weekend (178_, 173_, 373_, 374_, 171_) 1.3 (178DYE1A, 178DYE1AAP, 178DYE1AAT) | 178D6.011 | 09.2001-10.2004 |
| FIAT | PALIO Weekend (178_, 173_, 373_, 374_, 171_) 1.3 (178DYE1A, 178DYE1AAP, 178DYE1AAT) | 188A5.000 | 09.2001-10.2004 |
| FIAT | SIENA (178_, 172_, 372_) 1.3 | 188A5.000 | 09.2001-12.2009 |
| FIAT | UNO (195_) 1.4 (1951630, 1951830) | 327A.011 | 05.2010- |
Reference Information
| 042449 | DA SILVA |
| 10010332OV | ITAB AUTOMOTIVE |
| 20401233OE | REAL |
| 3129875 | HENKEL PARTS |
| 3129876 | HENKEL PARTS |
| 3129877 | HENKEL PARTS |
| 46763530 | FIAT |
| 46796553 | FIAT |
| 500.594.113.010 | WAI |
| 500.594.113.280 | WAI |
| 500.594.113.340 | WAI |
| 5010083 | MEAT & DORIA |
| 5010359 | MEAT & DORIA |
| 5010359G | MEAT & DORIA |
| 51888975 | FIAT |
| 51997820 | FIAT |
| 55209989 | FIAT |
| 6010332.1 | SANDO |
| BREF032F000C60004 | CARWOOD GROUP |
| CST10332GS | CASCO |
| F000C60001 | BOSCH |
| F000C60004 | BOSCH |
| MAV123320 | SIOM |
| S103254 | BTS TURBO |
| S132.689 | WAI |
| S144.245 | WAI |
| STR10343 | ELECTROLOG |
| UD103742S | AS-PL |
