Price:
NZ$ 281.78 including GST
NZ$ 245.03 excluding GST
or four payments of $70.45
with
Learn More
each
S0894S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 1 kW |
| Length (L.1) | 179 mm |
| Mount Hole Center - Center (O.1) | 66 mm |
| Mount Hole Center - Center (O.2) | 108 mm |
| Mount Hole Center - Center (O.3) | 71 mm |
| Mount Hole Diameter (C.1) | M8x1.25 mm |
| Mount Hole Diameter (C.2) | 9 mm |
| Mount Hole Diameter (C.3) | M8x1.25 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 11 mm |
| Rotation | CW |
| Spigot Diameter (A) | 64 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FIAT | Albea 1.3 | [188A5.000] | 09.2001-12.2009 |
| FIAT | Palio 1.0 | [178A1.000] | 04.1996-10.2003 |
| FIAT | Palio 1.0 | [178A3.011] | 04.1996-10.2003 |
| FIAT | Palio 1.2 | [178E2.000] | 06.1999-10.2002 |
| FIAT | Palio 1.3 | [178D6.011] | 03.2000-02.2003 |
| FIAT | Palio 1.3 | [188A5.000] | 03.2000-02.2003 |
| FIAT | Palio 1.3 | [188A5.000] | 09.2001-10.2004 |
Reference Information
| 10010332OV | ITAB AUTOMOTIVE |
| 20401233OE | REAL |
| 46763530 | FIAT |
| 46796553 | FIAT |
| 500.594.113.010 | PSH |
| 500.594.113.280 | PSH |
| 51888975 | FIAT |
| 51997820 | FIAT |
| 55209989 | FIAT |
| 6010332.1 | SANDO |
| BREF032F000C60004 | CARWOOD GROUP |
| CST10332GS | CASCO |
| F000C60004 | BOSCH |
| F000CD09A3 | BOSCH |
| MAV123320 | SIOM |
| S103254 | BTS TURBO |
| S12BH0018 | SIDAT |
| S132.689 | PSH |
| STR10343 | ELECTROLOG |
| UD103742S | AS-PL |
