Price:
NZ$ 293.27 including GST
NZ$ 255.02 excluding GST
or four payments of $73.32
with
Learn More
each
S1199S
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
Specifications
| Kilowatt | 1.20 kW |
| Length (L.1) | 202 mm |
| Mount Hole Center - Center (O.1) | 95 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 14 mm |
| Rotation | CW |
| Spigot Diameter (A) | 75 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | i30 1.4 | [G4LC] | 01.2014-05.2017 |
| HYUNDAI | i30 1.4 | [G4LC] | 12.2014- |
| HYUNDAI | i30 1.4 | [G4LC] | 12.2014-12.2016 |
| HYUNDAI | i30 1.4 MPi | [G4LC] | 03.2017-12.2020 |
| HYUNDAI | i30 1.4 MPi | [G4LC] | 05.2015-05.2017 |
| HYUNDAI | i30 1.4 MPi | [G4LC] | 11.2016-12.2020 |
| HYUNDAI | i30 1.4 T-GDi | [G4LD] | 03.2017-12.2020 |
| HYUNDAI | i30 1.4 T-GDi | [G4LD] | 11.2016-12.2020 |
| HYUNDAI | i30 Fastback 1.4 T-GDi | [G4LD] | 06.2017- |
| HYUNDAI | i30 Hatchback 1.4 MPi | [G4LC] | 05.2015-05.2017 |
| KIA | Ceed 1.4 | [G4LC] | 03.2018-12.2020 |
| KIA | Ceed 1.4 LPG | [G4LC] | 12.2018-12.2020 |
| KIA | Ceed 1.4 MPi | [G4LC] | 04.2015-07.2018 |
| KIA | Ceed 1.4 T-GDi | [G4LD] | 03.2018-12.2020 |
| KIA | Ceed 1.4 T-GDi | [G4LD] | 04.2018-12.2020 |
| KIA | Ceed Hatchback 1.4 T-GDi | [G4LD] | 03.2018-12.2020 |
| KIA | Ceed Sportswagon 1.4 | [G4LC] | 04.2018-12.2020 |
| KIA | Ceed Sportswagon 1.4 LPG | [G4LC] | 12.2018-12.2020 |
| KIA | Ceed Sportswagon 1.4 MPi | [G4LC] | 04.2015-07.2018 |
| KIA | Ceed Sportswagon 1.4 T-GDi | [G4LD] | 04.2018-12.2020 |
| KIA | Pro Ceed 1.4 MPi | [G4LC] | 04.2015-07.2018 |
| KIA | Pro Ceed 1.4 MPi | [G4LC] | 07.2013-07.2018 |
| KIA | Pro Ceed 1.4 T-GDi | [G4LD] | 10.2018-12.2020 |
| KIA | Rio 1.4 | [G4LC] | 01.2017- |
| KIA | Stonic 1.4 CVVT | [G4LC] | 07.2017- |
| KIA | Stonic 1.4 LPG | [G4LC] | 11.2018- |
| KIA | XCeed 1.4 T-GDi | [G4LD] | 06.2019-12.2020 |
Reference Information
| 11040937 | EUROTEC |
| 12621 | EAI |
| 150.932.132.030 | PSH |
| 150.932.132.390 | PSH |
| 221101A | ERA |
| 25-5227 | ELSTOCK |
| 256422 | KUHNER |
| 256422D | KUHNER |
| 3112098 | HENKEL PARTS |
| 31314N | WAI / TRANSPO |
| 326200132 | DRI |
| 36100-03701 | HYUNDAI / KIA |
| 36100-03706 | HYUNDAI / KIA |
| 3692 | CEVAM |
| 61005424 | DELCO |
| 621ST21 | STARTCAR |
| 8000685 | DELCO |
| 88213902 | POWERMAX |
| AC-CBS6014 | ACAUTO |
| ANM99945 | ANDEL |
| DRS1022 | DELCO |
| DS2132 | DELCO |
| DS2132N | DELCO |
| EX3610003701 | MANDO |
| HY9047 | SNRA |
| LRS04063 | LUCAS |
| LRS4063 | LUCAS |
| S102503 | BTS TURBO |
| S102504 | BTS TURBO |
| ST02183 | TMI |
| STD5880 | KRAUF |
| STR2260 | ELECTROLOG |
| STX200832 | STARDAX |
| UD103739S | AS-PL |
