Price:
NZ$ 493.37 including GST
NZ$ 429.02 excluding GST
or four payments of $123.34
with
Learn More
UOM:
each
Product Code:
S1285S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 1.50 kW |
| Length (L.1) | 306 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 127 mm |
| Mount Hole Diameter (C.1) | 10.50 mm |
| Mount Hole Diameter (C.2) | 10.50 mm |
| Mount Hole Diameter (C.3) | 10.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 47 mm |
| Rotation | CW |
| Spigot Diameter (A) | 88.50 mm |
| Unit Type | DELCO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CATERPILLAR | V100 | ||
| CATERPILLAR | V120 | ||
| CATERPILLAR | V140 | ||
| HYSTER | C350A | ||
| HYSTER | C530 | ||
| HYSTER | C550A | ||
| HYSTER | H10-150F | ||
| HYSTER | H110-150F | ||
| HYSTER | H160-110E | ||
| HYSTER | H40-60JS | ||
| HYSTER | P40 | ||
| HYSTER | P50A |
Reference Information
| 10455326 | DELCO |
| 10455350 | DELCO |
| 10465412 | DELCO |
| 10465426 | DELCO |
| 10465449 | DELCO |
| 1108447 | DELCO |
| 1109097 | DELCO |
| 140-10112 | ROBERT'S |
| 1903105M91 | MASSEY FERGUSON |
| 201-10107 | DIXIE |
| 3004016 | HYSTER |
| 3231196 | DELCO |
| 347199 | CATERPILLAR |
| 3T8194 | CATERPILLAR |
| 518670M91 | MASSEY FERGUSON |
| 640.067.103.030 | PSH |
| 655380 | CATERPILLAR |
| 695324 | CATERPILLAR |
| 6F6848 | CATERPILLAR |
| 772482M91 | MASSEY FERGUSON |
| 7N8402 | CATERPILLAR |
| 7N8403 | CATERPILLAR |
| STR20037 | WOODAUTO |
| UD102954S | AS-PL |
| WOOSTR20037 | WOODAUTO |
