Price:
NZ$ 376.11 including GST
NZ$ 327.05 excluding GST
or four payments of $94.03
with
Learn More
each
S2136S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 1 kW |
| Length (L.1) | 197 mm |
| Mount Hole Center - Center (O.1) | 86 mm |
| Mount Hole Center - Center (O.2) | 88 mm |
| Mount Hole Center - Center (O.3) | 26 mm |
| Mount Hole Diameter (C.1) | M8x1.25 mm |
| Mount Hole Diameter (C.2) | M8x1.25 mm |
| Mount Hole Diameter (C.3) | M8x1.25 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 31.50 mm |
| Rotation | ACW |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MARINER | 40E | [36.1ci-40H.P.] | 01.1978-12.1980 |
| MARINER | 40EL | [36.1ci-40H.P.] | 01.1978-12.1980 |
| MARINER | 55E | [55H.P.] | 01.1984-01.1985 |
| MARINER | 60EL | [49.8ci-60H.P.] | 01.1978-12.1983 |
| SUZUKI | DT50EL | [44.1ci-50H.P.] | 01.1980-12.1983 |
| SUZUKI | DT50ES | [44.1ci-50H.P.] | 01.1980-12.1982 |
| SUZUKI | DT65EL | [48.7ci-65H.P.] | 01.1980-12.1982 |
| SUZUKI | DT65ES | [48.7ci-65H.P.] | 01.1980-12.1982 |
| YAMAHA | C55ELR | 01.1991-12.1995 | |
| YAMAHA | C55TLR | 01.1993-12.1995 |
Reference Information
| 10020249OV | ITAB AUTOMOTIVE |
| 104-10384 | ROBERT'S |
| 114261 | CARGO |
| 18313 | LESTER |
| 18313N | WAI / TRANSPO |
| 20445942OE | REAL |
| 240-10103 | DIXIE |
| 254929 | KUHNER |
| 31100-95240 | SUZUKI |
| 31100-95242 | SUZUKI |
| 50-47072M | MERCURY |
| 50-47072T | MERCURY |
| 50-81490M | MERCURY |
| 50-92669M | MERCURY |
| 50-97072M | MERCURY |
| 50-97072T | MERCURY |
| 6020249.1 | SIDAT |
| 676-81800-10-00 | YAMAHA |
| 697-81800-10-00 | YAMAHA |
| 697-81800-11-00 | YAMAHA |
| 697-81800-12-00 | YAMAHA |
| 697-81800-13-00 | YAMAHA |
| 71-25-18313 | WILSON |
| CST20249GS | CASCO |
| DRS1014 | DELCO |
| F032114261 | BOSCH |
| HT2-0058N | JUST PARTS |
| S114-220 | HITACHI |
| S114-221 | HITACHI |
| S114-221E | HITACHI |
| S114-221F | HITACHI |
| S114-221G | HITACHI |
| S114-221H | HITACHI |
| S114-221J | HITACHI |
| SHI0087 | ARROWHEAD |
| ST-18313 | RCP |
| STR3128 | ELECTROLOG |
| STR72034 | WOODAUTO |
| UD102441S | AS-PL |
| WOOSTR72034 | WOODAUTO |
