Price:
NZ$ 346.22 including GST
NZ$ 301.06 excluding GST
or four payments of $86.56
with
Learn More
each
S2143S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 1.40 kW |
| Length (L.1) | 233 mm |
| Mount Hole Center - Center (O.1) | 77 mm |
| Mount Hole Diameter (C.1) | 8.50 mm |
| Mount Hole Diameter (C.2) | 8.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 17.50 mm |
| Rotation | ACW |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| YAMAHA | 200 HP Two Stroke (VMAX HPDI) | 01.2005-12.2005 | |
| YAMAHA | 225 HP Two Stroke (VMAX HPDI) | 01.2003-12.2006 | |
| YAMAHA | 250 HP (HPDI) | 01.2003-12.2006 | |
| YAMAHA | 250 HP (VMAX HPDI) | 01.2003-12.2003 | |
| YAMAHA | LZ250TUR | 01.2003-12.2006 | |
| YAMAHA | LZ250TXR | 01.2003-12.2006 | |
| YAMAHA | VZ200TLR | 01.2005-12.2007 | |
| YAMAHA | VZ225HTLR | 01.2008-12.2010 | |
| YAMAHA | VZ225TLR | 01.2003-12.2007 | |
| YAMAHA | VZ250FTLR | 01.2008-12.2010 | |
| YAMAHA | VZ250TLR | 01.2003-12.2007 | |
| YAMAHA | Z250TUR | 01.2003-12.2006 | |
| YAMAHA | Z250TXR | 01.2003-12.2006 |
Reference Information
| 10020250OV | ITAB AUTOMOTIVE |
| 104-10395 | ROBERT'S |
| 106371 | FARCOM |
| 18441 | LESTER |
| 18441N | WAI / TRANSPO |
| 20445052OE | REAL |
| 256744 | KUHNER |
| 6020250.1 | SANDO |
| 60V-81800-00-00 | YAMAHA |
| 60X-81800-00-00 | YAMAHA |
| 71-25-18441 | WILSON |
| CST20250GS | CASCO |
| HT4-0077N | JUST PARTS |
| MAV222500 | SIOM |
| S114-863A | HITACHI |
| SHI0123 | ARROWHEAD |
| SHI250 | AUTOTEAM |
| STH3322 | KRAUF |
| UD102474S | AS-PL |
