Price:
NZ$ 402.51 including GST
NZ$ 350.01 excluding GST
or four payments of $100.63
with
Learn More
each
S2153S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 4 kW |
| Length (L.1) | 227 mm |
| Mount Hole Center - Center (O.1) | 120 mm |
| Mount Hole Diameter (C.1) | 12 mm |
| Mount Hole Diameter (C.2) | 12 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 95 mm |
| Rotation | CW |
| Spigot Diameter (A) | 9 mm |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CATERPILLAR | Engine | [4D32] | |
| CHAOCHAI | Engine | [CYQD32] | |
| DACHAI | Engine | [498] | |
| NISSAN | Engine 2.7 | [TD27] |
Reference Information
| 1-593-25W | WAI / TRANSPO |
| 3708010-C118 | CHANGAN |
| 3708010-C797 | CHANGAN |
| 3708010-C979A | CHANGAN |
| 3708010-C992 | CHANGAN |
| QDJ2418 | DONGFENG |
| QDJ2538 | DONGFENG |
| STQ3538 | KRAUF |
| UD103262S | AS-PL |
