S6524S
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
Specifications
| Kilowatt | 1.40 kW |
| Length (L.1) | 190 mm |
| Mount Hole Center - Center (O.1) | 115 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 20 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | 4 Runner 2.4 4WD | 01.1994-12.1995 | |
| TOYOTA | 8FG35N 3.7 | [1FS] | 01.2014-12.2019 |
| TOYOTA | 8FG35U 3.7 | [1FS] | 01.2014-12.2019 |
| TOYOTA | 8FG40N 3.7 | [1FS] | 01.2014-12.2019 |
| TOYOTA | 8FG40U 3.7 | [1FS] | 01.2014-12.2019 |
| TOYOTA | 8FG45N 3.7 | [1FS] | 01.2014-12.2019 |
| TOYOTA | 8FG45U 3.7 | [1FS] | 01.2014-12.2019 |
| TOYOTA | 8FG50N 3.7 | [1FS] | 01.2014-12.2019 |
| TOYOTA | 8FG50U 3.7 | [1FS] | 01.2014-12.2019 |
| TOYOTA | 8FG60U 3.7 | [1FS] | 01.2014-12.2019 |
| TOYOTA | 8FG70U 3.7 | [1FS] | 01.2014-12.2019 |
| TOYOTA | 8FG80U 3.7 | [1FS] | 01.2014-12.2019 |
| TOYOTA | 8FGC35U 3.7 | [1FS] | 01.2014-12.2019 |
| TOYOTA | 8FGC45U 3.7 | [1FS] | 01.2014-12.2019 |
| TOYOTA | 8FGC55U 3.7 | [1FS] | 01.2014-12.2019 |
| TOYOTA | 8FGC60U 3.7 | [1FS] | 01.2014-12.2019 |
| TOYOTA | 8FGC70U 3.7 | [1FS] | 01.2014-12.2019 |
| TOYOTA | 8FGCSU20 2.2 | [4Y] | 01.2012-12.2019 |
| TOYOTA | 8FGCU15 2.2 | [4Y] | 01.2012-12.2019 |
| TOYOTA | 8FGCU18 2.2 | [4Y] | 01.2012-12.2019 |
Reference Information
28100-36770 256504D 438080-1470 20432565OE 91-29-5292N DENDSN2133 S103134 91-29-5292 19493N 28100-36770-71 DSN2133 STN1144 438000-1470 6040565.1 190-20379 UD102513S 190.958.092.050 CST40565GS 190.958.092.260View your shopping basket or Browse other items in Starter Motors.
