Specifications
Kilowatt | 7.80 kW |
Length (L.1) | 340 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 28 mm |
Mount Hole Center - Center (O.3) | 64 mm |
Mount Hole Center - Center (O.4) | 126 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | 12 mm |
Mount Hole Diameter (C.3) | M12x1.75 mm |
Mount Hole Diameter (C.4) | 12 mm |
No./Mount holes | 4 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CATERPILLAR | 324D | ||
CATERPILLAR | 324D-L | ||
CATERPILLAR | 326D | ||
CATERPILLAR | 328D-LCR | ||
CATERPILLAR | 329D | ||
CATERPILLAR | 329D-L | ||
CATERPILLAR | M325D-LMH | ||
CATERPILLAR | M325D-MH |
Reference Information
109563 | FARCOM |
190-90136 | ROBERT'S |
190-90136N | ROBERT'S |
20R4880 | CATERPILLAR |
3949674 | CATERPILLAR |
428000-1150 | DENSO |
STN2796 | KRAUF |
UD102962S | AS-PL |
