Price:
NZ$ 570.10 including GST
NZ$ 495.74 excluding GST
or four payments of $142.53
with
Learn More
each
S6647S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 2.50 kW |
| Length (L.1) | 319 mm |
| Mount Hole Center - Center (O.1) | 102 mm |
| Mount Hole Center - Center (O.2) | 89 mm |
| Mount Hole Center - Center (O.3) | 125 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 47 mm |
| Rotation | CW |
| Spigot Diameter (A) | 88 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DODGE | Pickup 5.9 V6 | 01.1989- |
Reference Information
| 0986UR1959 | BOSCH |
| 10465535 | DELCO |
| 104895 | FARCOM |
| 113101 | CARGO |
| 128000-4910 | DENSO |
| 128000-4911 | DENSO |
| 17215N | WAI / TRANSPO |
| 19011812 | DELCO |
| 190-25282 | ROBERT'S |
| 2-1397-ND | WAI / TRANSPO |
| 255061 | KUHNER |
| 323546 | DELCO |
| 3604630RX | CUMMINS |
| 3912084 | CUMMINS |
| 3935890 | CUMMINS |
| 4428221 | CHRYSLER |
| 830.561.133.050 | PSH |
| 830.561.133.058 | PSH |
| 91295141 | WILSON |
| 9712809-491 | DENSO |
| A72790 | ATL AUTOTECHNIK |
| AC-CBS5304 | ACAUTO |
| CMA-621877 | COMLINE |
| F032113101 | CARGO |
| RNL4910ND | RNL |
| S105523 | BTS TURBO |
| S8244 | DIXIE |
| SR6501X | BOSCH |
| STN3101 | KRAUF |
| STR6085 | UNIPOINT |
| STR6696 | ELECTROLOG |
| STR70174 | WOODAUTO |
| UD102956S | AS-PL |
| WOOSTR70174 | WOODAUTO |
