Price:
NZ$ 731.77 including GST
NZ$ 636.32 excluding GST
or four payments of $182.94
with
Learn More
each
S9409S
No stock in NZ currently
No stock in NZ currently
Specifications
| Insulated Earth | Yes |
| Kilowatt | 5.50 kW |
| Length (L.1) | 344 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 12 qty |
| Pinion at Rest (B) | 48 mm |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BOMAG | BC 772 EB-2 11.9 | [TCD2015] | |
| BOMAG | MPH 122-2 11.9 | [TCD2015] | |
| BOMAG | MPH 125 15.9 | [TCD2015] | |
| BOMAG | MPH 600 15.9 | [TCD16] | |
| BOMAG | MPH 600 15.9 | [TCD2015] | |
| DEUTZ | 7545RTS 11.9 | [TCD2015] | |
| DEUTZ | Engine 11.9 | [TCD120V6] | |
| DEUTZ | Engine 11.9 | [TCD2015V06] | |
| DEUTZ | Engine 11.9 | [TCD2015V08] | |
| DEUTZ | Engine 15.9 | [BF8M1015] | |
| DEUTZ | Engine 15.9 | [BFM1015M] | |
| MATROT | M41H 11.9 | [BF6M1015] | |
| MATROT | M41H 11.9 | [TCD2015] | |
| PRINOTH | RT 400 11.9 | [TCD2015] | |
| SENNEBOGEN | 870 M 11.9 | [TCD2015] | |
| SENNEBOGEN | 870 R 11.9 | [TCD2015] | |
| WIRTGEN | RX 4500 11.9 | [TCD2015] | |
| WIRTGEN | SF 2600i | [TCD12] |
Reference Information
| 01183035 | KHD |
| 03050437 | KHD |
| 10021610OV | ITAB AUTOMOTIVE |
| 107293 | FARCOM |
| 11.131.609 | ISKRA / LETRIKA |
| 11.131.871 | ISKRA / LETRIKA |
| 182-30174 | ROBERT'S |
| 182-30174NOE | ROBERT'S |
| 20419016OE | REAL |
| 255159 | KUHNER |
| 255159M | KUHNER |
| 273-42206 | DIXIE |
| 511.506.123.090 | PSH |
| 511.506.123.311 | PSH |
| 6021610.1 | SANDO |
| 72735691 | MAHLE |
| 8950 | CEVAM |
| AZF4657 | ISKRA / LETRIKA |
| AZF4698 | ISKRA / LETRIKA |
| CST21610GS | CASCO |
| IS1211 | ISKRA / LETRIKA |
| MAHMS63 | WOODAUTO |
| MAV236100 | SIOM |
| MS63 | MAHLE |
| S104374 | BTS TURBO |
| S104375 | BTS TURBO |
| S133.244 | PSH |
| S144.131 | PSH |
| SIS610 | AUTOTEAM |
| STI9846 | KRAUF |
| STR7867 | ELECTROLOG |
| STRS408 | 3EFFE |
| TS-6290 | DIXIE |
| UD102998S | AS-PL |
| WG2045315 | WILMINK GROUP |
