Price:
NZ$ 664.15 including GST
NZ$ 577.52 excluding GST
or four payments of $166.04
with
Learn More
each
S9451S
No stock in NZ currently
No stock in NZ currently
Specifications
| Kilowatt | 5.50 kW |
| Length (L.1) | 350 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 128 mm |
| Mount Hole Diameter (C.1) | 11.50 mm |
| Mount Hole Diameter (C.2) | 11.50 mm |
| Mount Hole Diameter (C.3) | 11.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 32 mm |
| Rotation | CW |
| Spigot Diameter (A) | 88.50 mm |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CATERPILLAR | 312E | [C4.4] | 01.2012-12.2016 |
| CATERPILLAR | 312EL | [C4.4] | 01.2012-12.2018 |
| CATERPILLAR | 314E | [C4.4] | 01.2013-12.2015 |
| CATERPILLAR | 314E CR | [C4.4] | 01.2013-12.2015 |
| CATERPILLAR | 314E LCR | [C4.4] | 01.2013-12.2016 |
| CATERPILLAR | 314E SR | [C4.4] | 01.2013-12.2016 |
| CATERPILLAR | 316EL | [C4.4] | 01.2012-12.2016 |
| CATERPILLAR | 318EL | [C4.4] | 01.2012-12.2017 |
| CATERPILLAR | CP54B | [C4.4] | 01.2012-12.2019 |
| CATERPILLAR | CP68B | [C4.4] | 01.2012-12.2019 |
| CATERPILLAR | CP74B | [C4.4] | 01.2012-12.2019 |
| CATERPILLAR | CS54B | [C4.4] | 01.2012-12.2012 |
| CATERPILLAR | CS64B | [C4.4] | 01.2012-12.2012 |
| CATERPILLAR | CS66B | [C4.4] | 01.2012-12.2012 |
| CATERPILLAR | CS68B | [C4.4] | 01.2012-12.2012 |
| CATERPILLAR | CS74B | [C4.4] | 01.2012-12.2012 |
| CATERPILLAR | CS76B | [C4.4] | 01.2012-12.2012 |
| CATERPILLAR | CS78B | [C4.4] | 01.2012-12.2012 |
Reference Information
| 10021618OV | ITAB AUTOMOTIVE |
| 107932 | FARCOM |
| 11.131.899 | ISKRA / LETRIKA |
| 11.132.187 | ISKRA / LETRIKA |
| 182-30458 | ROBERT'S |
| 20419816OE | REAL |
| 255553 | KUHNER |
| 255553M | KUHNER |
| 3218968 | PERKINS |
| 3826587 | PERKINS |
| 6021618.1 | SANDO |
| 701.517.103.090 | PSH |
| 701.517.103.310 | PSH |
| 72735775 | MAHLE |
| AZF4699 | ISKRA / LETRIKA |
| AZF4839 | ISKRA / LETRIKA |
| CST21618GS | CASCO |
| IS1294 | ISKRA / LETRIKA |
| MAHMS147 | WOODAUTO |
| MS147 | MAHLE |
| S103313 | BTS TURBO |
| S104081 | BTS TURBO |
| S135.099 | PSH |
| S144.923 | PSH |
| SIS618 | AUTOTEAM |
| STI4839 | KRAUF |
| STR60747 | WOODAUTO |
| STR79288 | ELECTROLOG |
| T411409 | PERKINS |
| TS-6258 | DIXIE |
| UD102603S | AS-PL |
| WOOSTR60747 | WOODAUTO |
