Price:
NZ$ 535.83 including GST
NZ$ 465.94 excluding GST
or four payments of $133.96
with
Learn More
each
S9508S
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
Specifications
| Kilowatt | 3.20 kW |
| Length (L.1) | 277 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 24 mm |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | 433 2.5 | [D-155] | 01.1986-06.1990 |
| CASE | 433E 2.5 | [D-155] | 01.1975-12.1992 |
| CASE | 533 2.5 | [D-155] | 01.1986-06.1990 |
| CASE | 533A 2.5 | [D-155] | 01.1979-12.1992 |
| CASE | 533E 2.5 | [D-155] | 01.1979-12.1992 |
| CASE | 540 2.5 | [D-155] | 01.1988-12.1993 |
| CASE | 540 2.5 | [D-155] | 01.1994- |
| CASE | 633 2.9 | [D-179] | 01.1986-06.1990 |
| CASE | 633 2.9 | [D-179] | 01.1986-12.1991 |
| CASE | 633A 2.9 | [D-179] | 01.1986-12.1991 |
| CASE | 633A 3.0 | [D-179] | 01.1986-12.1990 |
| CASE | 633E 2.9 | [D-179] | 01.1986-12.1991 |
| CASE | 633V 2.9 | [D-179] | 01.1986-12.1991 |
| CASE | 640 2.5 | [D-179] | 06.1990-12.1993 |
| CASE | 640A 2.5 | [D-179] | 06.1990-12.1993 |
| CASE | 833 3.9 | [D-239] | 09.1981-12.1990 |
| CASE | 833A 3.9 | [D-239] | 01.1986-12.1990 |
| CASE | 833A 3.9 | [D-239] | 09.1981-12.1990 |
| CASE | 833E 3.9 | [D-239] | 09.1981-12.1990 |
| IH | 433 2.5 | [D-155] | 06.1973-12.1985 |
| IH | 433V 2.5 | [D-155] | 06.1973-12.1985 |
| IH | 533 2.5 | [D-155] | 06.1973-12.1985 |
| IH | 533V 2.5 | [D-155] | 06.1973-12.1985 |
| IH | 633A 3.0 | [D-179] | 01.1975-12.1985 |
| IH | 633E 3.0 | [D-179] | 01.1975-12.1985 |
| IH | 633V 3.0 | [D-179] | 01.1975-12.1985 |
| IH | TD633 | [D-155] | 01.1975-12.1985 |
| IH | TD633 | [D-179] | 01.1975-12.1985 |
| IH | TD633A | [D-155] | 01.1975-12.1985 |
| IH | TD633A | [D-179] | 01.1975-12.1985 |
| IH | TD633E | [D-155] | 01.1975-12.1985 |
| IH | TD633E | [D-179] | 01.1975-12.1985 |
| IH | TD633V | [D-155] | 01.1975-12.1985 |
| IH | TD633V | [D-179] | 01.1975-12.1985 |
Reference Information
| 0986017290 | BOSCH |
| 10021211AV | ITAB AUTOMOTIVE |
| 10021211OV | ITAB AUTOMOTIVE |
| 11.132.154 | ISKRA / LETRIKA |
| 112135 | CARGO |
| 138207A1 | CASE |
| 20419112BN | REAL |
| 20419112OE | REAL |
| 3055523R92 | CASE |
| 3218192EX | CASE |
| 3218674R91 | CASE |
| 3228192R91 | CASE |
| 540.525.113.090 | PSH |
| 540.525.113.310 | PSH |
| 6021211.0 | SANDO |
| 6021211.1 | SANDO |
| 72735851 | MAHLE |
| 8159 | CEVAM |
| 8EA015642-381 | HELLA |
| A186180 | CASE |
| AZE4239 | ISKRA / LETRIKA |
| CST21211AS | CASCO |
| CST21211GS | CASCO |
| F032112135 | CARGO |
| IS1384 | ISKRA / LETRIKA |
| MS223 | MAHLE |
| PRSL817 | 3EFFE |
| STR79361 | ELECTROLOG |
| STRL817 | 3EFFE |
| STX210073 | STARDAX |
| UD102339S | AS-PL |
| WG2044980 | WILMINK GROUP |
