Price:
NZ$ 163.89 including GST
NZ$ 142.51 excluding GST
or four payments of $40.97
with
Learn More
each
S9800S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 0.60 kW |
| Length (L.1) | 171 mm |
| Mount Hole Center - Center (O.1) | 60 mm |
| Mount Hole Diameter (C.1) | 6.50 mm |
| Mount Hole Diameter (C.2) | 7 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 41 mm |
| Rotation | CW |
| Unit Type | MITSUBA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| POLARIS | Ranger 570 4x4 | [567cc] | 01.2014-12.2014 |
| POLARIS | Ranger 570 4x4 Crew | [567cc] | 01.2014-12.2015 |
| POLARIS | RZR 570 EFI | [567cc] | 01.2012-12.2015 |
| POLARIS | Sportsman 570 ACE | [567cc] | 01.2015-12.2015 |
| POLARIS | Sportsman 570 ACE EFI | [567cc] | 01.2015-12.2015 |
| POLARIS | Sportsman 570 ACE HD | [567cc] | 01.2015-12.2015 |
| POLARIS | Sportsman 570 EFI | [567cc] | 01.2014-12.2014 |
| POLARIS | Sportsman 570 EFI EPS | [567cc] | 01.2014-12.2014 |
| POLARIS | Sportsman 570 EFI EPS Forest | [567cc] | 01.2014-12.2014 |
| POLARIS | Sportsman 570 EFI HD | [567cc] | 01.2014-12.2015 |
| POLARIS | Sportsman 570 EFI UTE HD | [567cc] | 01.2014-12.2014 |
| POLARIS | Sportsman 570 Forest | [567cc] | 01.2014-12.2014 |
| POLARIS | Sportsman 570 SP EPS | [567cc] | 01.2015-12.2015 |
| POLARIS | Sportsman 570 SP MD | [567cc] | 01.2015-12.2015 |
| POLARIS | Sportsman 570 Touring EFI | [567cc] | 01.2015-12.2015 |
Reference Information
| 106-10429 | ROBERT'S |
| 19494 | LESTER |
| 19494N | WAI / TRANSPO |
| 400.533.092.190 | PSH |
| 4013015 | POLARIS |
| 410-54238 | J&N |
| 71-26-19494 | WILSON |
| S133.050 | PSH |
| SMU0548 | ARROWHEAD |
| UD19161S | AS-PL |
