Price:
NZ$ 294.53 including GST
NZ$ 256.11 excluding GST
or four payments of $73.63
with
Learn More
UOM:
each
Product Code:
S9830S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 0.80 kW |
| Length (L.1) | 180 mm |
| Mount Hole Center - Center (O.1) | 34 mm |
| Mount Hole Diameter (C.1) | 6.50 mm |
| Mount Hole Diameter (C.2) | 6.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 38.10 mm |
| Rotation | CW |
| Unit Type | MITSUBA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SUZUKI | VL800 C50 Boulevard Cruiser | [805cc] | 01.2005-12.2011 |
| SUZUKI | VL800 Intruder Volusia | [805cc] | 01.2001-12.2004 |
| SUZUKI | VL800T C50T Boulevard Touring | [805cc] | 01.2005-12.2011 |
| SUZUKI | VL800T Intruder Volusia | [805cc] | 01.2001-12.2004 |
| SUZUKI | VS700GL Intruder | [700cc] | 01.1986-12.1987 |
| SUZUKI | VS750GLP Intruder | [750cc] | 01.1988-12.1991 |
| SUZUKI | VS800GL Intruder | [805cc] | 01.1992-12.2008 |
| SUZUKI | VS800 S50 Boulevard | [805cc] | 01.2005-12.2009 |
| SUZUKI | VX800 | [800cc] | 01.1990-12.1993 |
| SUZUKI | VZ800 M50 Boulevard Cruiser | [805cc] | 01.2005-12.2000 |
Reference Information
| 128000-8160 | DENSO |
| 128000-8161 | DENSO |
| 18787 | LESTER |
| 18787N | WAI / TRANSPO |
| 191-497 | PIC |
| 31100-38A00 | SUZUKI |
| 31100-38A01-H17 | SUZUKI |
| 31100-38A10 | SUZUKI |
| 31100-45C00 | SUZUKI |
| 31100-45C01 | SUZUKI |
| 71-26-18787 | WILSON |
| SMU0181 | ARROWHEAD |
| SZ2-0052N | JUST PARTS |
| UD102693S | AS-PL |
