Price:
NZ$ 146.13 including GST
NZ$ 127.07 excluding GST
or four payments of $36.53
with
Learn More
each
S9841S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 0.40 kW |
| Length (L.1) | 198 mm |
| Mount Hole Center - Center (O.1) | 22 mm |
| Mount Hole Diameter (C.1) | 6.50 mm |
| Mount Hole Diameter (C.2) | 6.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 39 mm |
| Rotation | CW |
| Unit Type | MITSUBA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SUZUKI | LS 650 Boulevard S40 0.7 | 01.1986-12.2016 | |
| SUZUKI | LS 650 Savage 0.7 | 01.1986-12.2000 | |
| SUZUKI | LS 650 Savage Pathfinder 0.7 | 01.1998-12.2000 |
Reference Information
| 10439165 | ALANKO |
| 10439174 | ALANKO |
| 108710 | FARCOM |
| 11439165 | ALANKO |
| 11439174 | ALANKO |
| 128000-3130 | DENSO |
| 128000-3131 | DENSO |
| 128000-4980 | DENSO |
| 128000-4981 | DENSO |
| 18799 | LESTER |
| 18799N | WAI / TRANSPO |
| 228000-6490 | DENSO |
| 255294 | KUHNER |
| 31100-07F00 | SUZUKI |
| 31100-24B00 | SUZUKI |
| 31100-24B10 | SUZUKI |
| 31100-24B11 | SUZUKI |
| 31100-24B11-H17 | SUZUKI |
| 400.569.092.050 | PSH |
| STN1508 | KRAUF |
| UD102708S | AS-PL |
