Price:
NZ$ 201.34 including GST
NZ$ 175.08 excluding GST
or four payments of $50.34
with
Learn More
UOM:
each
Product Code:
S9859S
Quantity In Stock Nationally
No stock in NZ currently
No stock in NZ currently
Specifications
| Kilowatt | 0.60 kW |
| Length (L.1) | 164 mm |
| Mount Hole Center - Center (O.1) | 70 mm |
| Mount Hole Diameter (C.1) | 6 mm |
| Mount Hole Diameter (C.2) | 6 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 41.50 mm |
| Rotation | ACW |
| Unit Type | MITSUBA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SUZUKI | DL 650 V-Strom | [645cc] | 01.2004- |
| SUZUKI | DL 650 V-Strom | [645cc] | 01.2004-12.2013 |
| SUZUKI | DL 650 V-Strom | [645cc] | 01.2015- |
| SUZUKI | DL 650 V-Strom | [645cc] | 01.2017- |
| SUZUKI | DL DL 650 V-Strom (C7) | 01.2015- | |
| SUZUKI | DL DL 650 V-Strom (C7) | 01.2015- | |
| SUZUKI | DL DL 650 V-Strom (WC70) | 01.2017- | |
| SUZUKI | DL DL 650 V-Strom (WC71) | 01.2017- | |
| SUZUKI | DL DL 650 V-Strom (WVB1) | 01.2004- | |
| SUZUKI | DL DL 650 V-Strom (WVB1) | 01.2004-12.2013 | |
| SUZUKI | Gladius 650 | [645cc] | 01.2009-12.2015 |
| SUZUKI | GLADIUS Gladius 650 (WVCX) | 01.2009-12.2015 | |
| SUZUKI | SV 650 | [645cc] | 01.2003-12.2006 |
| SUZUKI | SV 650 | [645cc] | 01.2007-12.2009 |
| SUZUKI | SV 650 | [645cc] | 12.1998-12.2002 |
| SUZUKI | SV 650 A | [645cc] | 01.2016- |
| SUZUKI | SV 650 Limited Edition | [645cc] | 01.2001-12.2002 |
| SUZUKI | SV 650 S | [645cc] | 01.2003-12.2006 |
| SUZUKI | SV 650 S | [645cc] | 01.2007-12.2009 |
| SUZUKI | SV 650 S | [645cc] | 12.1998-12.2002 |
| SUZUKI | SV SV 650 | 01.2007-12.2009 | |
| SUZUKI | SV SV 650 (AV) | 12.1998-12.2002 | |
| SUZUKI | SV SV 650 (AV) | 12.1998-12.2002 | |
| SUZUKI | SV SV 650 A (WCX0) | 01.2016- | |
| SUZUKI | SV SV 650 Limited Edition (AV) | 01.2001-12.2002 | |
| SUZUKI | SV SV 650 Limited Edition (AV) | 01.2001-12.2002 | |
| SUZUKI | SV SV 650 S (AV) | 12.1998-12.2002 | |
| SUZUKI | SV SV 650 S (AV) | 12.1998-12.2002 | |
| SUZUKI | SV SV 650 S (WVBX) | 01.2003-12.2006 | |
| SUZUKI | SV SV 650 S (WVBX) | 01.2003-12.2006 | |
| SUZUKI | SV SV 650 S (WVBY) | 01.2007-12.2009 | |
| SUZUKI | SV SV 650 S (WVBY) | 01.2007-12.2009 | |
| SUZUKI | SV SV 650 (WVBX) | 01.2003-12.2006 | |
| SUZUKI | SV SV 650 (WVBX) | 01.2003-12.2006 | |
| SUZUKI | SV SV 650 (WVBY) | 01.2007-12.2009 | |
| SUZUKI | VZ 800 Marauder | [805cc] | 01.1997-12.2006 |
| SUZUKI | VZ VZ 800 Marauder (AF) | 01.1997-12.2006 | |
| SUZUKI | VZ VZ 800 Marauder (AF) | 01.1997-12.2006 |
Reference Information
| 108239 | FARCOM |
| 180.545.092.190 | WAI |
| 18789 | LESTER |
| 18789N | WAI |
| 256263 | KUHNER |
| 31100-19F00 | SUZUKI |
| 31100-19F10 | SUZUKI |
| UD102737S | AS-PL |
