Price:
NZ$ 151.82 including GST
NZ$ 132.02 excluding GST
or four payments of $37.96
with
Learn More
each
S9773S
S9875S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
- This is the latest version and has a 108mm Long Field Case and a 9T Pinion
- This version replaces the longer bodied 10T version S9773S
| Kilowatt | 0.35 kW |
| Length (L.1) | 197 mm |
| Mount Hole Center - Center (O.1) | 67 mm |
| Mount Hole Diameter (C.1) | 9 mm |
| Mount Hole Diameter (C.2) | 9 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 32 mm |
| Rotation | ACW |
| Unit Type | JOHNSON ELECTRIC |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| KOHLER | Courage Twin SV710 |
Reference Information
| 256227 | KUHNER |
| 32-098-08 | KOHLER |
| 32-098-08-S | KOHLER |
| 32-098-10-S | KOHLER |
| 34009N | WAI / TRANSPO |
| 590.954.092.200 | PSH |
