Price:
NZ$ 530.20 including GST
NZ$ 461.04 excluding GST
or four payments of $132.55
with
Learn More
each
S9886S
No stock in NZ currently
No stock in NZ currently
Associated Numbers
11132394
11132236
11132621
azf4424
azf4381
azf4341
is1420
47605262
90386242
15133343
Specifications
| Kilowatt | 4.20 kW |
| Length (L.1) | 347 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 129 mm |
| Mount Hole Diameter (C.1) | 10.50 mm |
| Mount Hole Diameter (C.2) | 10.50 mm |
| Mount Hole Diameter (C.3) | 10.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 27 mm |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | Maxxum 115 4.5 | [FPT] | 01.2015-12.2022 |
| CASE | Maxxum 125 4.5 | [FPT] | 01.2015-12.2022 |
| CASE | Maxxum 135 4.5 | [FPT] | 01.2015-12.2021 |
| CASE | Maxxum 145 4.5 | [FPT] | 01.2015-12.2021 |
| CASE | Maxxum 150 6.7 | [FPT] | 01.2015-12.2021 |
| CASE | Optum 270 6.7 CVT | [FPT] | 01.2016-12.2020 |
| CASE | Optum 300 6.7 CVT | [FPT] | 01.2016-12.2020 |
| NEW HOLLAND | T6.125 4.5 | [FPT] | 01.2015-12.2020 |
| NEW HOLLAND | T6.145 4.5 | [FPT] | 01.2015-12.2021 |
| NEW HOLLAND | T6.155 4.5 | [FPT] | 01.2015-12.2022 |
| NEW HOLLAND | T6.160 4.5 | [FPT] | 01.2018-12.2022 |
| NEW HOLLAND | T6.165 6.7 | [FPT] | 01.2015-12.2022 |
| NEW HOLLAND | T6.175 6.7 | [FPT] | 01.2015-12.2022 |
| NEW HOLLAND | T6.180 6.7 | [FPT] | 01.2015-12.2021 |
| NEW HOLLAND | T7.175 6.7 | [FPT] | 01.2015-12.2020 |
| NEW HOLLAND | T7.190 6.7 | [FPT] | 01.2015-12.2021 |
| NEW HOLLAND | T7.210 6.7 | [FPT] | 01.2015-12.2021 |
| NEW HOLLAND | T7.225 6.7 | [FPT] | 01.2015-12.2020 |
| NEW HOLLAND | T7.230 6.7 | [FPT] | 01.2015-12.2021 |
| NEW HOLLAND | T7.245 6.7 | [FPT] | 01.2015-12.2021 |
| NEW HOLLAND | T7.260 6.7 | [FPT] | 01.2015-12.2022 |
| NEW HOLLAND | T7.270 6.7 | [FPT] | 01.2015-12.2022 |
| NEW HOLLAND | T7.290 6.7 | [FPT] | 01.2016-12.2020 |
| NEW HOLLAND | T7.315 6.7 | [FPT] | 01.2015-12.2021 |
Reference Information
| 10021247AV | ITAB AUTOMOTIVE |
| 11.132.236 | ISKRA / LETRIKA |
| 11.132.394 | ISKRA / LETRIKA |
| 11.132.621 | ISKRA / LETRIKA |
| 182-30540 | ROBERT'S |
| 20419742BN | REAL |
| 25-5369 | ELSTOCK |
| 256749 | KUHNER |
| 256749M | KUHNER |
| 47605262 | CASE |
| 540.524.103.090 | PSH |
| 540.524.103.310 | PSH |
| 6021247.0 | SANDO |
| 618042102 | DRI |
| 72412081 | MAHLE |
| 8959 | CEVAM |
| 90386242 | FORD |
| 91-23-6577 | WILSON |
| AZF4341 | ISKRA / LETRIKA |
| AZF4381 | ISKRA / LETRIKA |
| CST21247AS | CASCO |
| IS1420 | ISKRA / LETRIKA |
| LRS04207 | LUCAS |
| LRS4207 | LUCAS |
| MAHMS724 | WOODAUTO |
| MAV232470A | SIOM |
| MS724 | MAHLE |
| S104421 | BTS TURBO |
| S143.632 | PSH |
| S144.678 | PSH |
| ST02826 | TMI |
| STI3339 | KRAUF |
| STR79419 | ELECTROLOG |
| UD102340S | AS-PL |
| WG2045372 | WILMINK GROUP |
