Specifications
Length (L.1) | 161 mm |
Mount Hole Center - Center (O.1) | 46 mm |
Mount Hole Diameter (C.1) | 6 mm |
Mount Hole Diameter (C.2) | 7 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 42 mm |
Rotation | ACW |
Unit Type | MITSUBA |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HONDA | CB 500 F | [471cc] | 01.2013- |
HONDA | CB 500 X | [471cc] | 01.2013- |
HONDA | CBR 1000 S2 M/C | [999cc] | 01.2017- |
HONDA | CBR 500 R | [471cc] | 01.2013- |
Reference Information
109565 | FARCOM |
256754 | KUHNER |
30823N | WAI / TRANSPO |
31200-MFL-003 | HONDA |
31200-MGZ-J01 | HONDA |
31200-MGZ-J81 | HONDA |
SMU0476 | ARROWHEAD |
STU2991 | KRAUF |
UD102686S | AS-PL |
