Price:
NZ$ 525.76 including GST
NZ$ 457.18 excluding GST
or four payments of $131.44
with
Learn More
each
S9899S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 4.5 kW |
| Length (L.1) | 48 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 30 mm |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CATERPILLAR | 312GC | ||
| CATERPILLAR | 312GX | ||
| CATERPILLAR | 313 | ||
| CATERPILLAR | 313GC | ||
| CATERPILLAR | 313GX | ||
| CATERPILLAR | 315 | ||
| CATERPILLAR | 315GC | ||
| CATERPILLAR | 315GX | ||
| CATERPILLAR | 316GC | ||
| CATERPILLAR | 316GX | ||
| CATERPILLAR | 317GC | ||
| CATERPILLAR | CW34 | ||
| CATERPILLAR | M313-07 | ||
| CATERPILLAR | M314 | ||
| CATERPILLAR | M315 | ||
| HYUNDAI | HX140L | ||
| HYUNDAI | HX145LCR | ||
| HYUNDAI | HX160L | ||
| HYUNDAI | HX180L | ||
| HYUNDAI | R125LCR-9A | ||
| HYUNDAI | R140LC-9A | ||
| HYUNDAI | R145CR-9A | ||
| HYUNDAI | R160LC-9A | ||
| HYUNDAI | R180LC-9A | ||
| PERKINS | 1204 | ||
| PERKINS | 1204E | ||
| PERKINS | 1204E-E44TA 4.4 | ||
| PERKINS | 1204E-E44TTA 4.4 |
Reference Information
STR60742 STR79284 31485N 3472163 T406500 WOOSTR60742 6021621.1 6021621.0 MS717 STI2787 CST21621AS AZF4243 11.131.894 182-30508 IS1292 UD21624S 20419126OE S104417 ZUAC00428 20419126BN 11.132.370 CST21621GS MAHMS717 AZF4374 72411838 RNLMS717 256007MView your shopping basket or Browse other items in Starter Motors.
