A01069S - Brand new AS-PL Alternator

Brand new AS-PL Alternator
Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 489.49 including GST

NZ$ 425.64 excluding GST



or four payments of $122.37 with
Afterpay Payment Offer Learn More

A01069S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Purchase Qty:

Amp65 A
Diameter (D.1)8.50 mm
Diameter (D.2)8.50 mm
Length (L.1)181.00 mm
Mount Inside Length or Pad Mount C-C (C)56.00 mm
Plug CodePL_3200
Pulley Grooves1 qty
Pulley Groove Width (W.1)10.00 mm
Pulley Outside Diameter (O.D.1)46.50 mm
Pulley Outside Diameter (O.D.2)73.00 mm
Pulley to Mount Distance (A)109.00 mm
Pulley TypeAP
Voltage12 V
Make Model Type Year
AUDI 50 1.1 [HC] 08.1974-07.1977
AUDI 50 1.3 [HH] 08.1977-07.1978
VW Caddy 1.6 D [CR] 08.1982-07.1992
VW Caddy 1.6 D [JK] 08.1982-07.1992
VW Caddy 1.6 D [ME] 08.1982-07.1992
VW Golf 1.1 [FA] 04.1974-07.1983
VW Golf 1.1 [GG] 04.1974-07.1983
VW Golf 1.3 [GF] 08.1979-07.1983
VW Golf 1.5 D [CK] 08.1976-07.1980
VW Golf 1.6 D [CR] 08.1980-07.1983
VW Golf 1.6 D [JK] 08.1980-07.1983
VW Golf 1.6 TD [CY] 03.1982-07.1983
VW Jetta 1.1 [GG] 08.1979-02.1984
VW Jetta 1.3 [GF] 08.1979-02.1984
VW Passat B1 1.3 [FY] 05.1973-07.1980
VW Passat B1 1.3 [FZ] 01.1978-07.1980
VW Passat B2 1.3 [FY] 08.1980-07.1983
VW Passat B2 1.3 [FZ] 08.1980-07.1986
VW Scirocco 1.3 [GF] 08.1979-07.1980
VW Scirocco 1.3 [GF] 08.1980-12.1983
