Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 963.93 including GST
NZ$ 838.20 excluding GST
or four payments of $240.98
with
Learn More
S01081S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 6.60 kW |
| Length (L.1) | 405.00 mm |
| Mount Hole Center - Center (O.1) | 90.00 mm |
| Mount Hole Center - Center (O.2) | 90.00 mm |
| Mount Hole Center - Center (O.3) | 127.00 mm |
| Mount Hole Diameter (C.1) | 11.00 mm |
| Mount Hole Diameter (C.2) | 11.00 mm |
| Mount Hole Diameter (C.3) | 11.00 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 47.00 mm |
| Rotation | CW |
| Spigot Diameter (A) | 89.00 mm |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LIEBHERR | Engine 10.0 | [D926] | |
| LIEBHERR | Engine 6.6 | [D924] | |
| LIEBHERR | Engine TI-E A2 9884022 | [D926] | |
| VOLVO | Engine | [TD122KHE] | |
| VOLVO | Engine 12.0 | [TD122] |
