Brand new AS-PL Alternator
PREMIUM LINE
SEG Automotive
BOSCH
Price:
NZ$ 1,199.66 including GST
NZ$ 1,043.18 excluding GST
or four payments of $299.92
with
Learn More
Product Code:
S01181(SEG)
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 3.00 kW |
| Length (L.1) | 314.00 mm |
| Mount Hole Center - Center (O.1) | 105.00 mm |
| Mount Hole Diameter (C.1) | 13.00 mm |
| Mount Hole Diameter (C.2) | 13.00 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 23.00 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82.50 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DEUTZ-FAHR | AGROLUX 70 | F4L913 | 01.2001-12.2006 |
| DEUTZ-FAHR | AGROTRON 4.80 MK1 | BF4M1012E | 01.1995-12.1997 |
| DEUTZ-FAHR | AGROTRON 80 | BF4M2012E | 01.2004-12.2004 |
| DEUTZ-FAHR | Series 5 G 5090.4 | 02.2013- | |
| DEUTZ-FAHR | Series 5 G 5105.4 | 02.2013- | |
| DEUTZ-FAHR | Series 5 G 5115.4 | 02.2013- | |
| FIAT | 500 (111_, 101_, 110_) 0.5 (110F) | 110F.000 | 01.1965-12.1975 |
| FIAT | 500 (111_, 101_, 110_) 0.5 (110F) | 120.000 | 01.1965-12.1975 |
| FIAT | 500 (111_, 101_, 110_) 0.6 | 111A000 | 08.1968-01.1976 |
| LAMBORGHINI | 105 Diesel Formula | 1004.4 | 03.1989-12.1999 |
| LAMBORGHINI | 1106 5.5 Diesel 2M | 916.6 | 01.1984-12.1999 |
| LAMBORGHINI | 115 6.0 Diesel Formula | 1000.6 | 12.1989-12.1999 |
| LAMBORGHINI | 1306 5.5 TD DT | 916.6 | 01.1984-12.1999 |
| LAMBORGHINI | 1506 6.8 TD | 1106HT | 01.1984-12.1999 |
| LAMBORGHINI | 1706 6.8 TD | 1106 | 01.1984-12.1999 |
| LAMBORGHINI | 660 3.1 Diesel | 105.3 | 01.1987-12.1999 |
| LAMBORGHINI | 660 F 3.0 Diesel | 1000.3 | 06.1987-12.1999 |
| LAMBORGHINI | 775 F 3.0 Diesel Plus | 1000.3 | 05.1991-12.1999 |
| LAMBORGHINI | 956-2 RM 5.5 Diesel | 916.6 | 01.1984-12.1999 |
| LAMBORGHINI | 956 DT 5.5 Diesel | 916.6 | 01.1984-12.1999 |
| LAMBORGHINI | C 664 3.1 Diesel | 06.1987-12.2000 | |
| LAMBORGHINI | CRONO 80 | 10.2009- | |
| LAMBORGHINI | R2 R2.100, R2 TARGEDT 100 | 10.2013- | |
| LAMBORGHINI | R2 R2.90, R2 TARGET 90 | 10.2013- | |
| LAMBORGHINI | RF / RS / RV RF 110 | 10.2009- | |
| LAMBORGHINI | RF / RS / RV RF 90, RF 100 | 10.2009- | |
| LAMBORGHINI | RF / RS / RV RS 100, RS 110 | 10.2009- | |
| LAMBORGHINI | RF / RS / RV RS 90 | 10.2009- | |
| LAMBORGHINI | RF / RS / RV RS 90 | 10.2009- | |
| SAME | DORADO 100.4 | 11.2013- | |
| SAME | DORADO 76 | 10.2004-12.2009 | |
| SAME | DORADO 86 | 1000.4WT | 10.2004-12.2009 |
| SAME | DORADO 86 | 1000.4WT | 10.2004-12.2009 |
| SAME | DORADO 90 | 09.2009- | |
| SAME | DORADO 90 | 11.2013- | |
| SAME | DORADO 90 | 11.2013- | |
| SAME | DORADO 90, 100 | 09.2009- | |
| SAME | DORADO 90.4 | 11.2013- | |
| SAME | DORADO 90.4 | 11.2013- | |
| SAME | EXPLORER 105.4 | 07.2014- | |
| SAME | EXPLORER 115.4 | 07.2014- | |
| SAME | Explorer 70 4.0 Diesel | 07.1986- | |
| SAME | EXPLORER 75 | 1000.4W | 10.2004-12.2007 |
| SAME | Explorer 80 4.0 Diesel | 07.1986- | |
| SAME | EXPLORER 85 | 1000.4WT | 10.2004-12.2007 |
| SAME | EXPLORER 90.4 | 07.2014- | |
| SAME | Explorer 90 4.0 Diesel | 06.1986- | |
| SAME | EXPLORER 95 | 1000.4WT | 10.2004-12.2007 |
| SAME | Frutteto 75 3.0 Diesel | 05.1991- | |
| SAME | Laser 110 5.7 Diesel | 01.1988- | |
| SAME | Laser 130 6.2 Diesel | 01.1988- | |
| SAME | LASER 140 | 1000.6WTI | 10.2010- |
| SAME | Laser 150 6.2 Diesel | 01.1988- | |
| SAME | LASER 160 | 1000.6WTI | 10.2010- |
| SAME | Solar 60 3.1 Diesel | 06.1986- | |
| STEYR | 8110 5.2 | WD611.. | 07.1984- |
| STEYR | 8130 5.2 | WD611.. | 07.1984- |
