Brand new AS-PL Alternator
PREMIUM LINE
AS-PL
BOSCH
Price:
NZ$ 291.42 including GST
NZ$ 253.41 excluding GST
or four payments of $72.86
with
Learn More
Product Code:
S0246PR
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 2.00 kW |
| Length (L.1) | 239.00 mm |
| Mount Hole Center - Center (O.1) | 83.00 mm |
| Mount Hole Center - Center (O.2) | 116.00 mm |
| Mount Hole Center - Center (O.3) | 83.00 mm |
| Mount Hole Diameter (C.1) | 9.00 mm |
| Mount Hole Diameter (C.2) | 9.00 mm |
| Mount Hole Diameter (C.3) | 8.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9. 11 qty |
| Pinion at Rest (B) | 9.50 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82.00 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FIAT | DOBLO Box Body/MPV (223_) 1.9 D (223ZXB1A) | 223A6.000 | 03.2001- |
| FIAT | DOBLO MPV (119_, 223_) 1.4 | 350A1.000 | 10.2005- |
| FIAT | DOBLO MPV (119_, 223_) 1.9 D (223AXB1A) | 223A6.000 | 03.2001- |
| FIAT | GRANDE PUNTO (199_) 1.4 (199AXB11, 199AXB1A, 199BXB1A, 199AXL1A) | 350A1.000 | 06.2005-12.2015 |
| FIAT | GRANDE PUNTO (199_) 1.4 Natural Power | 350A1.000 | 07.2008- |
| FIAT | IDEA (350_) 1.4 | 350A1.000 | 10.2005- |
| FIAT | IDEA (350_) 1.4 16V | 843A1.000 | 01.2004- |
| FIAT | PALIO Weekend (178_, 173_, 373_, 374_, 171_) 1.9 D | 223A6.000 | 03.2001- |
| FIAT | PALIO Weekend (178_, 173_, 373_, 374_, 171_) 1.9 JTD | 188A2.000 | 09.2001- |
| FIAT | PUNTO (188_) 1.4 | 843A1.000 | 09.2003-03.2012 |
| FIAT | PUNTO (188_) 1.9 DS 60 (188.031, .051, .231, .251) | 188A3.000 | 09.1999-03.2012 |
| FIAT | PUNTO (188_) 1.9 JTD | 188A7.000 | 10.2001-03.2012 |
| FIAT | PUNTO (188_) 1.9 JTD | 188B2.000 | 06.2003-03.2012 |
| FIAT | PUNTO (188_) 1.9 JTD 80 (188.237, .257, .337, .357) | 188A2.000 | 09.1999-03.2012 |
| FIAT | PUNTO Hatchback Van (188_) 1.9 D 60 | 188A3.000 | 02.2000-10.2009 |
| FIAT | PUNTO Hatchback Van (188_) 1.9 JTD | 188A7.000 | 02.2000-10.2009 |
| FIAT | STILO (192_) 1.9 JTD (192_XE1A) | 192A1.000 | 10.2001-11.2006 |
| FIAT | STILO (192_) 1.9 JTD (192_XE1A) | 192B4.000 | 10.2001-11.2006 |
| FIAT | STILO (192_) 1.9 JTD (192_XE1A) | 937A7.000 | 10.2001-11.2006 |
| FIAT | STILO (192_) 1.9 JTD (192_XF1A) | 192A3.000 | 02.2002-11.2006 |
| FIAT | STILO Multi Wagon (192_) 1.9 JTD | 192A1.000 | 01.2003-08.2008 |
| FIAT | STILO Multi Wagon (192_) 1.9 JTD | 192A3.000 | 01.2003-08.2008 |
| FIAT | STILO Multi Wagon (192_) 1.9 JTD | 192B4.000 | 01.2003-08.2008 |
| FIAT | STILO Multi Wagon (192_) 1.9 JTD | 937A7.000 | 01.2003-08.2008 |
| FIAT | STILO VAN (192_) 1.9 JTD (192DXE1A) | 192A1.000 | 10.2001-08.2005 |
| FIAT | STILO VAN (192_) 1.9 JTD (192DXF1A) | 192A3.000 | 10.2001-08.2005 |
| FIAT | STRADA Pickup (178_, 278_) 1.9 D | 223A6.000 | 12.2000- |
